Technical Specifications
OVERVIEW
Model Type : Monitored SYSTEM OVERVIEW
Voltage compatibility (VAC) : 120 OUTPUT
Frequency compatibility : 50 / 60 Hz
Output nominal voltage : 120V
Outlet quantity / type : 8 5-15/20R INPUT
Recommended Electrical Service : 120V
Maximum Input Amps (A) : 20
Input connection type : Attached L5-20P input cable plus 5-20P adapter
Plug Type : NEMA L5-20P (20A 120V), NEMA 5-20P (20A 120V)
Input cord length (ft.) : 12
Input cord length (m) : 3.6 LEDS ALARMS AND SWITCHES
Switches : n/a
Front panel LEDs :
Front panel digital display confirms power availability and PDU output current level in 1 amp increments PHYSICAL
Shipping weight (lbs) : 7
Shipping weight (kg) : 3.2
Unit Dimensions (HWD/in) : 1.7 x 17.3 x 6.2
Unit Dimensions (HWD/cm) : 4.3 x 43.9 x 15.7
Shipping Dimensions (HWD/in) : 2.09 x 11 x 20.5
Shipping Dimensions (HWD/cm) : 5.3 x 27.9 x 52.1
Unit weight (lbs) : 7
Unit weight (kg) : 3.2
Style : 1U Rackmount ENVIRONMENTAL
Relative Humidity : 0-95% non-condensing COMMUNICATIONS
SNMP compatibility :
Pre-installed SNMPWEBCARD provides remote monitoring via web, telnet, and SNMP management systems CERTIFICATIONS
Tested to UL 60950 (USA, Canada), Class A (Emissions), NOM (Mexico), RoHS compliant WARRANTY
2 Years
