Technical Specifications
PDU Type
Metered OUTPUT
Output Capacity Details:11.5kVA (with 415V input) / 11kVA (with 400V input) / 10.5kVA (with 380V input) total 16A per bank (balanced) Frequency compatibility:50 / 60 Hz
Output nominal voltage:Single phase 240V (with 415V input), 230V (with 400V input), 220V (with 380V input) Outlet quantity / type:45 total - 36 C13 (12 per phase), 9 C19 (3 per phase)
Outlet Type:IEC-C13, IEC-C19 INPUT
Nominal Input Voltage(s) Supported:380V AC 400V AC 415V AC
PDU Input Voltage:400 380 415
Maximum Input Amps (A):16
PDU Plug Type:IEC-309 16A RED (3P+N+E)
Input cord length (ft.):6
Input cord length (m):1.8
Phase:3-Phase Material of construction
Steel
Style
Vertical rackmount Form factors supported
Vertical rackmount installation supported with included mounting brackets supports toolless mounting in button-mount compatible racks
PDU Form Factor
Vertical (0U) Certifications:
Tested to UL (USA), CSA (Canada), NOM (Mexico), CE (EU), Class A (Emissions), RoHS (Hazardous Substances) Item Dimension (L"xW"xH"):
6.1 x 4.3 x 75.8
Weight:
13.8 lb
Warranty Information:
2-year limited warranty
