Technical Specifications
CPU
Build in Intel Socket 1151 Core i7/i5/i3 for Xeon E3-1200 v5 and 6th Generation Core Pentium and Celeron Processor
Support Intel 14nm CPU
Support Intel Turbo Boost Technology Chipset
Build in Intel C236 Memory
4 x DIMM, Max 64GB, DDR4 2133 MHz ECC, Non-ECC, Unbuffered Memory
Dual Channel Memory Architecture Graphics
Integrated Graphics Processor
Multi VGA Output Support: HDMI/DVI-D/DisplayPort Ports
- Supports HDMI with max. resolution 4096 x 2160 at 60 Hz / 4096 x 2160 at 24 Hz
- Supports DVI-D with max. resolution 1920 x 1200 at 60 Hz
- Supports DisplayPort with max. resolution 4096 x 2304 at 60 Hz
Maximum shared memory of 512 MB
Supports Intel HD Graphics, InTru 3D, Quick Sync Video, Clear Video HD Technology, Insider Expansion Slots
1 x PCIe 3.0/2.0 x1 (x1 Mode)
1 x PCIe 3.0/2.0 x16 (x16 Mode)
1 x PCIe 3.0 x4 (x8 Mode) Storage
Intel C236 Chipset:
8 x SATA 6Gb/s port(s)
1 x M.2 Socket 32, with M Key, type 2242/2260/2280/22110 storage devices support (both SATA and PCIE mode)
Support Raid 0, 1, 5, 10
Intel Rapid Storage Technology Enterprise supports LAN
Intel I210, 2 x Gigabit LAN Controllers
Support Teaming Technology Audio
Realtek ALC1150 8-Channel High Definition Audio CODEC
- Supports : Jack-detection, Multi-streaming, Front Panel MIC Jack-retasking
- High quality 112 dB SNR stereo playback output (Line-out at rear) and 104 dB SNR recording input (Line-in)
Audio Feature:
- Absolute Pitch 192kHz/ 24-bit True BD Lossless Sound
- DTS Connect
- DTS Studio Sound
- Optical S/PDIF out port(s) at back panel
- BD Audio Layer Content Protection
- Audio Shielding: Ensures precision analog/digital separation and greatly reduced multi-lateral interference
- Audio amplifier: Provides the highest-quality sound for headphone and speakers
- Premium Japanese-made audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity
- Top notch audio sensation delivers according to the audio configuration
Separate layer for left and right track, ensuring both sound deliver equal quality
USB Ports
Intel C236 Chipset:
- 4 x USB 2.0 Port(s) (2 at back Panel)
- 6 x USB 3.0 Port(s) (2 at Back Panel) Special Features
ASUS Digital Power Design: (3 -phase for CPU, 2 -phase for iGPU)
ASUS Quiet Thermal Solution: Stylish Fanless Design Heat-sink solution
ASUS EZ DIY:
- ASUS CrashFree BIOS 3
- ASUS EZ Flash Operating System Support
Windows 10
Windows 8.1
Windows 7 SP1
Windows Server 2008 R2
Windows Server 2012 R2 Back I/O Ports
1 x DVI-D
1 x DisplayPort
1 x HDMI
2 x LAN (RJ45) port(s)
2 x USB 3.0
2 x USB 2.0
1 x Optical S/PDIF out
1 x USB BIOS Flashback Button(s)
1 x 8-channel Audio I/O Internal I/O Ports
1 x AAFP connector
2 x USB 3.0 connector(s) support(s) additional 4 USB 3.0 port(s)
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
1 x M.2 Socket 3
1 x TPM header
8 x SATA 6Gb/s connector(s)
1 x CPU fan with PWM control
1 x S/PDIF out header(s)
1 x 8-pin EATX 12 V Power connector
1 x 24-pin EATX Power connector(s)
1 x Front panel connector(s) (1 x 19 -pin)
1 x AUX panel header(s)
4 x Front fan
1 x Rear fan
1 x COM port header
1 x Chassis intrusion header Accessories
Users manual
I/O Shield
1 x COM port cable(s)
8 x SATA 6Gb/s cable(s)
1 x SCD
1 x ASWM Enterprise SDVD
1 x OSG manual
1 x Metal Plate for LGA1151 BIOs
16 MB Flash ROM, EFI AMI BIOS, PnP, DMI3.0, WfM2.0, SM BIOS 3.0, ACPI 5.0a, ASUS EZ Flash Utility, ASUS CrashFree BIOS 3 Manageability
WfM 2.0, DMI 3.0, WOL by PME, WOR by PME, PXE Form Factor
mATX Form Factor Item Dimension (L"xW"xH")
11 x 13 x 3
Weight
4.10 lb
Warranty Information
3 Years with 1st Year ARS
