Technical Specifications
OVERVIEW
PDU Type
Switched
INPUT
PDU Input Voltage
100,120,127 Recommended Electrical Service
20A 120V Maximum Input Amps
20 Maximum Input Amps Details
Agency de-rated to 16A continuous PDU Plug Type
NEMA 5-20P,NEMA L5-20P Input Phase
Single-Phase Input Cord Length (m)
3.05
OUTPUT
Output Capacity Details
2.03kW (127V), 1.92kW (120V), 1.6kW (100V) / 20A total capacity (Agency de-rated to 16A),16A max per outlet Frequency Compatibility
50 / 60 Hz Output Receptacles
(24) 5-15/20R Output Nominal Voltage
100,120 ,127 Overload Protection
n/a Customized Load Management Receptacles
Each outlet is individually controllable via remote interface
USER INTERFACE, ALERTS and CONTROLS
Front Panel LCD Display
Digital display reports load level in amps for LOAD BANK 1 (Outlets 1-12), LOAD BANK 2 (Outlets 13-24), LOAD BANKS 1 and 2 COMBINED (Outlets 1-24) and each individual output receptacle,Digital display can also be used to scroll the configured IP address
