Technical Specifications
<b> OUTPUT </b><br>Output Volt Amp Capacity (VA): 1500 <br>Output kVA Capacity (kVA): 1.5 <br>Output Watt Capacity (Watts): 940 <br>Output Capacity Details: 940W watts maximum when used with internal batteries or 1 BP24V15RT2U battery pack Output is reduced to 600W maximum in all other external battery pack configurations <br>Nominal Output Voltage(s) Supported: 110V, 115V, 120V <br>Nominal Voltage Details: 115v nominal output in battery mode <br>Frequency Compatibility: 60 Hz <br>Output Voltage Regulation (Line Mode): -18%, +8% <br>Output Voltage Regulation (Battery Mode): +/- 5% <br>Output Receptacles: (8) 5-15R <br>UPS Output Receptacles (Surge Suppression Only): 6 UPS outlets, 2 surge-only outlets <br>Output AC Waveform (AC Mode): Sine wave <br>Output AC Waveform (Battery Mode): PWM sine wave <b>INPUT </b><br> Rated input current (Maximum Load): 12A <br>Nominal Input Voltage(s) Supported: 120V AC <br>UPS Input Connection Type: 5-15P <br>UPS Input Cord Length (ft.): 6 <br>UPS Input Cord Length (m): 1.8 <br>Recommended Electrical Service : 15A 120V <br>Input Phase: Single-Phase <b>BATTERY </b><br>Full Load Runtime (min.): 4 min. (940w) <br>Half Load Runtime (min.): 11.4 min. (470w) <br>Expandable Battery Runtime: Extended runtime supported via optional external battery packs <br>External Battery Pack Compatibility: BP24V15RT2U(limit 1) BP24V28-2U(limit 1) BP24V70-3U(multi-pack compatible) <br>DC System Voltage (VDC): 24 <br>Battery Recharge Rate (Included Batteries): Less than 4.5 hours from 10% to 90% <br>Internal UPS Replacement Battery Cartridge: RBC24-SLT <br>Battery Access: Battery access door <br>Battery Replacement Description: Hot-swappable, user replaceable batteries <br>Expandable Runtime: Yes <b>VOLTAGE REGULATION </b><br>Voltage Regulation Description: Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 75 to 147 <br>Overvoltage Correction: Input voltages between 128 and 147 are reduced by 12% <br>Undervoltage Correction: Input voltages between 93 and 107 are boosted by 14% <br>Severe Undervoltage Correction: Input voltages between 75 and 92 are boosted by 30% <b> USER INTERFACE, ALERTS and CONTROLS </b><br>Switches: 2 Switches control off/on power status and alarm-cancel/self-test operation <br>Alarm Cancel Operation: Power-fail alarm can be silenced using alarm-cancel switch once silenced, alarm will re-sound to indicate low-battery status <br>Audible Alarm: Audible alarm indicates power-failure and low-battery conditions <br>LED Indicators: 5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status <b> SURGE / NOISE SUPPRESSION </b><br>UPS AC Suppression Joule Rating: 510 <br>UPS AC Suppression Response Time: Instantaneous <br>UPS Dataline Suppression: 1 line TEL/DSL (1 in / 1 out) 10/100Base T Ethernet <br>EMI / RFI AC Noise Suppression: Yes <b> Installation Form Factors Supported with Included Accessories</b><br>Tower <b> Installation Form Factors Supported with Optional Accessories </b><br>Wallmount(UPSWM - tower mounting kit) <b> Primary Form Factor</b><br> Tower <b> UPS Housing Material</b><br> Polycarbonate <b> ENVIRONMENTAL </b><br>Operating Temperature Range: +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius <br>Storage Temperature Range: +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius <br>Relative Humidity: 0 to 95%, non-condensing <br>AC Mode BTU / Hr. (Full Load): 205 <br>Battery Mode BTU / Hr. (Full Load): 611 <br>AC Mode Efficiency Rating (100% Load): 90% <b>COMMUNICATIONS </b><br>Communications Interface: USB <br>PowerAlert Software: For local monitoring via the UPSs built-in USB port, download PowerAlert Local software at http://www.tripplite.com/poweralert <br>Communications Cable: USB cable included <br>WatchDog Compatibility: Supports Watchdog application, OS and hard-reboot restart options for remote applications <b>LINE / BATTERY TRANSFER </b><br>Transfer Time: 2-4 milliseconds <br>Low Voltage Transfer to Battery Power (Setpoint): 75 <br>High Voltage Transfer to Battery Power (Setpoint): 147 <b>SPECIAL FEATURES </b><br>Cold Start (Startup in Battery Mode During a Power Failure): Cold-start operation supported <br>High Availability UPS Features: Hot swappable batteries <b>CERTIFICATIONS </b><br>UPS Certifications Tested to UL1778 (USA) <br>Tested to CSA (Canada) <br>Tested to NOM (Mexico) <br>Meets FCC Part 15 Category B (EMI) <br> TAA Compliant <b>Item Dimension (L inchxW inchxH inch)</b><br> 12 x 11 x 16</b><br><br><b>Weight</b><br> 30.00 lb<br><br><b>Warranty Information</b><br> 3-Year limited warranty
