Technical Specifications
System
Main Processor: Intel Processors
Operating System: LINUX Video and Audio
IP Camera Input: 64 Channel
Two-Way Talk: 1 Channel Input, 1 Channel Output, RCA Display
Interface: 2 x HDMI (Up to 3840x2160), 1 VGA
Resolution: 3840x2160, 1920x1080, 1280x1024, 1280x720, 1024x768
Multi-Screen Display:
- The First Screen: 1/4/8/9/16/25/36
- The Second Screen: 1/4/8/9/16
OSD: Camera Title, Time, Video Loss, Camera Lock, Motion Detection, Recording Recording
Compression: H.264/MJPEG
Resolution: 12Mp, 8Mp, 6Mp, 5Mp, 3Mp, 1080P, 1.3Mp, 720P etc
Record Rate: 256Mbps
Bit Rate: 1 to 20 Mbps
Record Mode: Manual, Schedule (Regular (Continuous), MD (Video detection: Motion detection, Camera blank, Video loss), Alarm), Stop
Record Interval: 1 to 120 min (default: 60 min), Pre-record: 1 to 30 sec, Post-record: 10 to 300 sec Video Detection and Alarm
Trigger Events: Recording, PTZ, Tour, Alarm out, Video Push, Email, FTP, Snapshot, Buzzer Screen tips
Video Detection: Motion Detection, MD Zones: 396(2218), Video Loss Camera Blank
Alarm Input: 16ch, low level effective, green terminal interface
Relay Output: 8ch, Relay contact(1A at 24V DC), NO/NC programmable, green terminal interface Playback and Backup
Playback: 128Mbps in Raid 5 mode / 64Mbps in single HDD mode
Search Mode: Time/Date, Alarm, MD Exact search (accurate to second), Smart search
Playback Function: Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode: USB Device/Network/Internal SATA burner/eSATA Device Network
Interface: 2 x RJ-45 Ports (10/100/1000 Mbps)
Ethernet Ports: 2 Ethernet ports joint working or 2 independent 1000Mbps Ethernet ports
Network Function: HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search(Support Dahua IP camera, DVR, NVS and etc.)
Max User Function: 128 Users
Smart Phone: iPhone, iPad, Android, Windows Phone Storage
Internal HDD: 8 SATA III Ports, up to 48TB
HDD Mode: Single, RAID 0/5/6/10/50/60 (Support Global HDD Hot-Spare) Auxiliary Interface
USB: 4 x USB Ports (3 x USB 2.0, 1 x USB 3.0)
eSATA: 1 eSATA Port
RS232: 1 Port, For PC Communication and Keyboard
RS485: 1 Port For PTZ Control General
Power Supply: AC 110V to 240V 50/60Hz
Power Consumption: <40W (Without HDD)
Working Environment: -10 C to +55 C, 10% to 90% RH, 86 to 106kpa
Installed: 19inch Rackmount Item Dimension (L"xW"xH")
22 x 22 x 9
Weight
26.24 lb
Warranty Information
2 Years
