Technical Specifications
Standard and Protocol
IEEE802.3, IEEE802.3u Interface
Mesh5:1 Gigabit WAN/LAN Ethernet ports1 Gigabit LAN Ethernet ports
Mesh5s: 1 Megabit LAN Ethernet ports Antenna
Mesh5: 2x3dBi Built-in Omni-directional antennas
Mesh5s: 2x2dBi Built-in Omni-directional antennas Button
Mesh5: 1 reset button
Mesh5s: 1 reset button Power
Mesh5
Input: 100-240V-50/60Hz, 0.6A
Output: DC 12V1A
Mesh5s
Input: 100-240V-50/60Hz, 0.3A
Output: 9V800mA Indicator
Mesh5: System/Signal
Mesh5s: 1 System/Signal Wireless Standards
IEEE 802.11ac/a/n 5GHz
IEEE 802.11b/g/n 2.4GHz Data Rate
5GHz: Up to 867Mbps
2.4GHz: Up to 300Mbps Frequency
Simultaneous dual band 2.4GHz and 5GHz Basic Features
SSID Broadcast
Beamforming
Support MU-MIMO Wireless Security
WPA2-PSK(default) Wireless roaming
Comply with IEEE802.11k/v/r Internet Connection Type
PPPoE, Dynamic IP, Static IP, Bridge Mode DHCP Server
DHCP Server
DHCP Client List Virtual Server
Port Forwarding
UPnP Firewall
Forbid UDP flood attack
Forbid TCP flood attack
Forbid flood attack DNS
Support manually setting DNS server VPN
IPsec pass through
PPTP pass through
L2TP pass through Other
Parental Control
Guest Network
Firmware upgrade online
Reset to factory settings Setup Requirements
A mobile device running Android 4.0+ or iOS 8+
