Technical Specifications
Unmanaged Network Switch for Home/Small Offices, Workgroups and Security Applications16 twisted-pair RJ45 Gigabit Ethernet ports with PoE+ capabilityAuto-negotiable 10/100/1000 MbpsAutomatic MDI/MDIX cross-over detection32 Gbps switching capacity (2 Gbps per port with full duplex)LEDs indicate power, connection, activity and PoE status per portSupports 9k jumbo frames, MAC address auto-learning and auto-aging, and 802.3x flow control (full duplex) and back pressure (half duplex)Package Includes NG16POE 16-Port 10/100/1000 Mbps 1U Rack-Mount/Desktop Gigabit Ethernet Unmanaged Switch Detachable AC power cord with NEMA 5-15P plug, 6 ft. (2) Rack-mounting brackets (8) Screws (4) Rubber feet Owner?s manual260W Total PoE+ Budget Up to 30W PoE per port Each port supplies PoE+ power to connected devices via network cableHeavy-Duty Metal Housing Detachable 6 ft. AC power cord with NEMA 5-15P plug Plug-and-play?no configuration necessaryVersatile Installation Options Includes rubber feet for secure placement on flat desktop surface Mounts in 1U of EIA-standard 19 in. rack with included brackets Grounding lug includedLED Indicators Power LED (Red); Two LEDs per RJ-45 port (UPPER LED: Green indicates 10/100Mbps link; Amber indicates 1000Mbps link; LEDs flash to indicate port activity / LOWER LED: Green indicates POE is active)Electrical Consumption 400W maximum power consumption (at 100% switching capacity with 260W POE consumption)
