Technical Specifications
FORM FACTOR
Shuttle 0.85L Form Factor
PROCESSOR
Intel Kabylake-U Celeron 3865U 15W CPU
i3 7100U, i5 7200U, i7 7500U (optional)
MEMORY
2 x 260 pin DDR4 SODIMM slots, 16GB per DIMM (Max 32GB)
Dual Channel DDR4 2133 Mhz
VIDEO OUTPUT
Intel HD Graphics
AUDIO
Realtek ALC662 HD Audio
ETHERNET
Built in Intel I211 support 10/100/1000Mbs
Built in Realtek RTL8188EE 802.11 b/g/n Wireless LAN
STORAGE INTERFACE
Support SATA 6.0Gb/s bandwidth
BACK PANEL
(1)HDMI
(1)DisplayPort
(2)USB 2.0
(1)RJ45
(1)DC-in Jack
(1)Headphone+Mic in combo jack
(1)RS232
(1)Kensington Lock
DRIVE BAYS
(1)2.5" 15mm HDD / SSD
POWER
Automatics Voltage adjustment between 100 and 240VAC 50/60Hz
65 Watts (19V/3.42A), 2 pin
ACCESSORIES
Quickguide
DVD driver
VESA mount
Stand (optional)
Power adapter and cord
EXPANSION SLOT
M.2 2230 A,E key (Built in WIFI)
M.2 2280 M key
2.5" 15mm SATA
OS SUPPORT
Windows 10
Linux
Item Dimension (L inchxW inchxH inch)
6 x 6 x 2 Weight
1.00lb Warranty Information
3 Year
