SKU: GFM3TBT2RX |  Mfg. Part: MZBSWHP  | UPC: 813567022923  |
 1 Reviews  |     Share

MZBSWHP - Gigabyte Motherboard with Intel Celeron N3050

Special Order
Ships in 1-2 weeks
Condition: New

$138.71  $187.26
Need 10+? Request a volume quote
 Free Shipping for this Item

Product Overview

The Gigabyte MZBSWHP is a high-performance motherboard designed for efficient computing. Integrating the Intel Celeron N3050 processor, it supports a range of features for both business and personal applications. With various connectivity options and robust performance metrics, this motherboard is ideal for compact systems requiring reliability and speed.

Technical Specifications

  • Form Factor: Proprietary
  • Operating Temperature: 0C to 50C
  • Operating Humidity: 0 to 90% (non-condensing)
  • Non-Operating Temperature: -40C to 70C
  • Non-Operating Humidity: 0% to 95% (non-condensing)
  • CPU: Intel Celeron N3060, 2 cores, 2 threads, 1.6 to 2.48 GHz, 2MB L2 cache, 6W max TDP
  • Socket: 1 x BGA 1170
  • Memory: 2 x SO-DIMM slots, Up to 8GB DDR3L, 1333/1600MHz
  • Flash Memory: 8GB eMMC
  • LAN: 2 x GbE LAN ports (Realtek RTL8111HS)
  • Video: Intel HD Graphics supporting dual display, max resolution HDMI: 3840 x 2160 at 30Hz or 2560 x 1600 at 60Hz
  • Audio: Realtek ALC255, supports 2/4/5.1/7.1 channel configurations via HDMI
  • SATA: 1 x SATA 6Gb/s port
  • Expansion Slots: 1 x full-size mini-PCIe (3G or mSATA), 1 x half-size mini-PCIe (WiFi+BT)
  • Internal I/O: Multiple headers including USB 2.0, Serial, GPIO, SPI, and TPM
  • Rear I/O: Includes HDMI, RJ45, USB ports, Micro-B USB, SDXC card slot, Line-out/MIC-in
  • TPM: TPM header available
  • Supported OS: Windows 10/8.1/7, Android 5.1
  • Power Connectors: 12-19V DC-in or 12V connector
  • Weight: 1.00 lb
  • Warranty: 3 Years

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • GIGABYTE
  • MZBSWHP
  • 813567022923
  • New
  • 1 lbs
  • 0 X 0 X 0
  • Feb 19, 2026
  • Aug 04, 2016
Product Identifiers: Brand: Gigabyte • Part #: MZBSWHP • UPC: 813567022923 • Category: Motherboards

MZBSWHP - Gigabyte Motherboard with Intel Celeron N3050

Reviews for Gigabyte MZBSWHP

$138.71
