Cooler Master MPW5001ACAAN1US CoolerMaster Power Supply MPW-5001-ACAAN1-US Elite V3 500W ATX 12V Active PFC 120mm Non-Mo

ELITE V3

The new Elite V3 power supply is a dependable choice for the everyday PC user. The included 120mm quiet fan, PCI-E support, and global 3 year warranty delivers a PSU that provides function and resilience you can count on. It's the perfect option for users and applications that don't require 80 Plus efficiency to get the job done. This power supply has been engineered for reliability with a focus on reducing random shutdowns in brownout conditions when power sources are unstable. The Elite V3 is a complete solution delivering powerful stability in a small package for an affordable price.

Product Name
Elite V3 500W
Model
MPW-5001-ACAAN1-US
ATX Version
Intel ATX 12V V2.31
PFC
Active PFC (>0.9)
Input Voltage
100-240Vac
Input Current
10-5A
Input Frequency
50-60Hz
Fan Size
120mm
Fan Bearing
Sleeve Fan
Powergood Signal
100-500ms
Hold Up Time
>10ms at 100% Load
Efficiency
75% at Typical Load
MTBF
>100,000 Hours
Operating Temperature
10 to 40^oC
Protection
OVP / OPP / OTP / SCP
Regulatory
TUV, cTUVus, CE, FCC, BSMI
Connector
M/B 20+4 Pin
1
CPU 12V 4+4 Pin
1
SATA
6
Peripheral 4 Pin
3
FDD Cable 4 Pin
1
PCI-e 6+2 Pin
2
Item Dimension (L inchxW inchxH inch)
9 x 8 x 4

Weight
4.28lb

Warranty Information
3 Years
