SKU: MSQYD7QXYX |  Mfg. Part: MBD-X7SBI-LN4-O  | UPC: 672042025626  |
 1 Reviews  |     Share

Supermicro MBD-X7SBI-LN4-O QUAD-CORE/DUAL-CORE INTEL XEON 3000 SERIES PROCESSORS, INTEL 3200 CHIPSET 1333/1

Out of Stock
Condition: New

$287.87  $388.62
 Free Shipping for this Item

Product Overview

066/800MHZ FSB, 8GB OF UNB. ECC OR NON-ECC DDRII 667/800 SDRAM, 1 PCI-X 133 & 1

Technical Specifications

ATX MBD INTEL 3210 FOR 1U 8GB DDR2 800 6XSATA 4XLAN PRODUCT FEATURES: Enterprise MainBoard / ServerBoard Great connectivity with 4 Ethernet controllers
Product DescriptionSUPERMICRO X7SBi-LN4 - motherboard - ATX - Intel 3200
Product TypeMotherboard
Form FactorATX
Dimensions (WxDxH)12 in x 9.6 in
Chipset TypeIntel 3200 / Intel ICH9R
Multi-Core SupportDual-Core / Quad-core
Max Bus Speed1333 MHz
Processor0 ( 1 ) - LGA775 Socket
Compatible ProcessorsCore 2 Duo, Dual-Core Xeon 3000 series, Core 2 Quad, Quad-Core Xeon 3200 series
64-bit Processors CompatibilityYes
RAM0 MB (installed) / 8 GB (max)
Supported RAM TechnologyDDR2 SDRAM
Supported RAM Integrity CheckNon-ECC, ECC
Storage ControllerATA-100, Serial ATA-300 (RAID)
USB Ports Configuration8 x USB
Storage Ports Configuration1 x ATA, 6 x SATA
Graphics ControllerATI ES1000
Video Memory32 MB
NetworkingNetwork adapter - Intel 82573V / 82573L - Ethernet, Fast Ethernet, Gigabit Ethernet
General
Product TypeMotherboard
Form FactorATX
Width12 in
Depth9.6 in
Compatible ProcessorsCore 2 Duo, Dual-Core Xeon 3000 series, Core 2 Quad, Quad-Core Xeon 3200 series
64-bit Processors CompatibilityYes
Processor SocketLGA775 Socket
Multi-Core SupportDual-Core / Quad-core
Chipset TypeIntel 3200 / Intel ICH9R
Max Bus Speed1333 MHz
BIOS TypePhoenix
Storage ControllerATA-100, Serial ATA-300 (RAID)
Power Connectors24-pin main power connector, 8-pin ATX12V connector
Processor
Installed Qty (Max Supported)0 ( 1 )
Memory
Supported RAM TechnologyDDR2 SDRAM
Supported RAM Integrity CheckNon-ECC, ECC
RAM Installed ( Max )0 MB / 8 GB (max)
Supported RAM SpeedPC2-6400, PC2-5300
RAM FeaturesUnbuffered, dual channel memory architecture
Video
Graphics ControllerATI ES1000
Video Memory32 MB
Telecom / Networking
NetworkingNetwork adapter - Intel 82573V / 82573L - Ethernet, Fast Ethernet, Gigabit Ethernet
Features
BIOS FeaturesACPI 1.0 support, DMI 2.3 support, ACPI 2.0 support, SMBIOS 2.3 support, IPMI support
Hardware MonitoringCPU core temperature, chassis temperature, CPU fan tachometer, chassis fan tachometer, CPU core voltage
Sleep / Wake UpKeyboard wake up, wake on LAN (WOL), wake on ring (WOR)
Hardware FeaturesDiagnostic LEDs, chassis intrusion detection, Watch Dog Timer
Expansion / Connectivity
Expansion Slot(s)1 processor - LGA775 Socket
4 memory ( 1.8 V ) - DIMM 240-pin
1 PCI-X / 133 MHz
1 PCI
Storage InterfacesIntel ICH9R : Serial ATA-300 - connector(s): 6 x 7pin Serial ATA - 6 device(s) - RAID 0 / RAID 1 / RAID 10 / RAID 5
Intel ICH9R : ATA-100 - connector(s): 1 x 40pin IDC - 2 device(s)
Interfaces1 x storage - floppy interface - 34 pin IDC
4 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45
2 x Hi-Speed USB - 4 pin USB Type A
1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
1 x keyboard - generic - 6 pin mini-DIN (PS/2 style)
1 x mouse - generic - 6 pin mini-DIN (PS/2 style)
1 x serial - RS-232 - 9 pin D-Sub (DB-9)
1 x parallel - IEEE 1284 (EPP/ECP) - 25 pin D-Sub (DB-25)
Additional Connectors (Optional)6 x Hi-Speed USB
Miscellaneous
Software IncludedDrivers & utilities, SuperO Doctor III
Compliant StandardsPlug and Play, ACPI 2.0, RoHS


ATDZUID

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Supermicro
  • MBD-X7SBI-LN4-O
  • 672042025626
  • New
  • 3.22 lbs
  • 14 X 3 X 13
  • Feb 19, 2026
  • Jan 06, 2010
Product Identifiers: Brand: Supermicro • Part #: MBD-X7SBI-LN4-O • UPC: 672042025626

Supermicro MBD-X7SBI-LN4-O QUAD-CORE/DUAL-CORE INTEL XEON 3000 SERIES PROCESSORS, INTEL 3200 CHIPSET 1333/1
