Processor & ChipsetChipset Manufacturer: IntelTotal Processor Supported: 2Processor Socket: Socket P LGA-3647Processor Supported: XeonMemoryNumber of Memory Slots: 16Memory Form Factor: RDIMM, DIMM, LRDIMMMaximum Memory: 2 TBMemory Technology: DDR4 SDRAMMemory Speed Supported: 2.67 GHz, 2.40 GHz, 2.13 GHzI/O ControllerController Type: Serial ATA/600RAID Supported: YesRAID Levels: 10, 5, 1, 0VideoOnboard Video: On-board Video ChipsetGraphics Controller Manufacturer: ASPEEDGraphics Controller Model: AST2500AudioAudio Channels: 7.1Network & CommunicationGigabit Ethernet: YesI/O ExpansionsNumber of Total Expansion Slots: 6Total Number of PCI Express Slots: 6Number of PCI Express x8 Slots: 2Number of PCI Express x16 Slots: 4Interfaces/PortsTotal Number of USB Ports: 4Number of USB 3.0 Ports: 2VGA: YesOnboard InterfacesNumber of SATA Interfaces: 14Number of M.2 Interfaces: 1Total Number of Onboard USB Ports: 5Number of Onboard USB 3.0 Ports: 3Number of NVMe Ports: 2Physical CharacteristicsForm Factor: Extended ATXWidth: 13"Depth: 12"MiscellaneousCompatibility: SuperServer: SYS-6029P-TR SYS-7049P-TR SYS-2029P-C1R Chassis: SC745BAC-R1K28B2 213AC-R1K23LPB 825TQC-R1K03LPB
Technical Specifications
Form Factor E-ATX CPU Intel Xeon Scalable Processors. Dual Socket P (LGA 3647) supported, CPU TDP support 205W, 2 UPI up to 10.4 GT/s Memory Capacity Up to 2TB 3DS ECC RDIMM and DDR4-2666MHz, Up to 2TB 3DS ECC LRDIMM, in 16 DIMM slots Memory Type 2666/2400/2133MHz ECC DDR4 RDIMM, LRDIMM DIMM Sizes RDIMM: 64GB LRDIMM: 128GB 3DS LRDIMM: 128GB Memory Voltage 1.2V Error Detection Corrects single-bit errors Detects double-bit errors (using ECC memory) Chipset Intel C621 SATA Intel C621 controller for 14 SATA3 (6 Gbps) ports RAID 0,1,5,10 IPMI ASPEED AST2500 Network Controllers Dual LAN with 1GbE with Marvell 88E1512 Graphics Aspeed AST2500 BMC USB 5 USB 3.0 ports (2 rear + 2 via header(s) + 1 Type A) Video Output 1 VGA port(s) Serial Port / Header 2 COM Ports (1 rear, 1 header(s)) TPM 1 TPM Header Item Dimension (L inchxW inchxH inch) 14 x 11 x 3 Weight 3.00lb Warranty Information 1 Year
