Supermicro MBD-X11DPH-T-B(3YR) X11DPH-T-B Dual LGA3647/ Intel C622/ DDR4/ SATA3&USB3.0/ V&2GbE/ EATX Server Motherboard

Product SKUs
MBD-X11DPH-T:X11DPH-T
Physical Stats
Form Factor:E-ATX
Processor/Cache
CPU:Intel Xeon Scalable Processors.
Dual Socket P (LGA 3647) supported, CPU TDP support 205W, 3 UPI up to 10.4 GT/s
System Memory
Memory Capacity:Up to 2TB 3DS ECC RDIMM, DDR4-2666MHz Up to 2TB 3DS ECC LRDIMM, in 16 DIMM slots
Memory Type:2666/2400/2133MHz ECC DDR4 RDIMM, LRDIMM
DIMM Sizes:RDIMM: 64GB
LRDIMM: 64GB
3DS LRDIMM: 128GB
Memory Voltage:1.2V
Error Detection:Corrects single-bit errors
Detects double-bit errors (using ECC memory)
On-Board Devices
Chipset:Intel C622
SATA:Intel C622 controller for 10 SATA3 (6 Gbps) ports RAID 0,1,5,10
IPMI:ASPEED AST2500
Network Controllers:Dual LAN with 10GBase-T with Intel X557
Input / Output
SATA:10 SATA3 (6Gbps) ports
LAN:2 RJ45 10GBase-T ports
USB:7 USB 3.0 ports (4 rear + 2 headers + 1 Type A)
Video Output:1 VGA port
Serial Port / Header:1 COM Port (1 rear)
TPM:1 TPM Header
Expansion Slots
PCI-E:3 PCI-E 3.0 x16,
4 PCI-E 3.0 x8
M.2:M.2 Interface: 2 PCI-E 3.0 x4
Form Factor: 22110
Key: M-Key (RAID 0,1 support)
System BIOS
BIOS Type:AMI UEFI
Management
Software:Intel Node Manager, IPMI2.0, KVM with dedicated LAN, SPM, SSM, SUM, SuperDoctor 5, Watchdog
PC Health Monitoring
Voltage:+1.8V, +12V, +3.3V, +5V, +5V standby, 7-fan status, Chassis intrusion header, Monitors CPU voltages, Supports system management utility, System temperature, VBAT
FAN:7fan headers (up to 7 fans), 7 fans with tachometer status monitoring, Dual Cooling Zone, Fan speed control, Overheat LED indication, PWM fan speed control
Temperature:CPU thermal trip support, Monitoring for CPU and chassis environment, PECI
LED:CPU / System Overheat LED, UID/Remote UID, Suspend static indicator LED
Other Features:ACPI power management, Chassis intrusion detection, CPU thermal trip support for processor protection, Node Manager Support, RoHS, UID
Operating Environment
Operating Temperature Range:10^oC - 35^oC (50^oF - 95^oF)
Non-Operating Temperature Range:-40^oC - 70^oC (-40^oF - 158^oF)
Operating Relative Humidity Range:8% - 90% (non-condensing)
Non-Operating Relative Humidity Range:5% - 95% (non-condensing)
Item Dimension ( L inch x W inch x H inch)
12 x 13 x 1 Weight
3.00 lb Warranty Information
3 Years
