Gigabyte MA10-ST0 Mini-ITX Motherboard with Intel Atom C3958

Special Order
Ships in 1-2 weeks
Condition: New

$880.46  $1,188.62
 Free Shipping for this Item

Product Overview

The Gigabyte MA10-ST0 is a high-performance Mini-ITX motherboard designed for servers and industrial applications. Powered by the Intel Atom C3958 SoC, this motherboard supports robust features for efficient processing and connectivity.

With its dual-channel DDR4 support and multiple LAN ports, it offers reliable network capabilities and ample memory options.

Technical Specifications

  • Form Factor: Mini-ITX, 170W x 170D (mm)
  • CPU: Intel Atom C3958 SoC, 2.0GHz, 16 cores, 16MB L2 cache
  • TDP: 31W, DDR4 Frequency up to 2400MHz
  • Socket: 1 x BGA 1310
  • Memory: 4 x DDR4 slots, Dual channels, up to 128GB ECC R-DIMM or 64GB ECC/non-ECC UDIMM
  • Flash Memory: 32GB eMMC
  • LAN Ports: 2 x 10Gb/s SFP+, 2 x 1Gb/s (Intel I210-AT), 1 x 10/100/1000 management LAN
  • Video: Integrated Aspeed AST2400, 1920x1200 at 60Hz
  • SATA: 4 x Mini-SAS up to 16 x SATA 6Gb/s
  • RAID: Not supported
  • Expansion Slots: 1 x PCIe x8 (Gen3)
  • Internal I/O: Multiple power connectors, fan headers, and interface connectors
  • Rear I/O: Power button with LED, multiple USB ports, and LAN ports
  • TPM: 1 x TPM header with LPC interface
  • Operating System Supported: Windows Server, Red Hat, SuSE, Ubuntu, Fedora
  • Management: Aspeed AST2400 management controller with IPMI capabilities
  • Operating Properties: Temperature range from 10°C to 40°C, up to 80% humidity

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • GIGABYTE
  • MA10-ST0
  • 889523010761
  • New
  • 2.25 lbs
  • 16 X 5 X 12
  • Apr 25, 2026
  • Oct 07, 2017
Product Identifiers: Brand: Gigabyte • Part #: MA10-ST0 • UPC: 889523010761
