Technical Specifications
Environment: Internal sub-systems with up to 122 SAS or SATA II drives Physical Dimensions: Full-height, half-length (6.6?X 4.2? Connectors: Four SAS SFF8087 x4 internal connectors Device Support: Up to 122 devices supported Host Bus Type: x8 lane PCI Express 1.0a compliant PCI Power Management Specification 1.1 compliant Data Transfer Rates: Up to 3Gb/s per port I/O Processor/SAS Controller: Intel IOP333 @ 500MHz/LSI SAS1068 Cache Memory: 256MB DDR II SDRAM integrated Battery Backup Unit: LSIiBBU01, an optional intelligent Battery Backup Unit and 20-pin, 10-inch cable for remote connection RAID and Fault Tolerant Features: - RAID levels 0, 1, and 5; RAID spans 10 and 50; - Online Capacity Expansion (OCE), Online RAID Level Migration (RLM), Auto resume after loss of system power during array rebuild or reconstruction (RLM); - Configure stripe size up to 128k, Fast initialization for quick array setup, Check Consistency for background data integrity, Patrol read for media scanning and repairing, 64 logical drive support; - DDF compliant Configuration on Disk (COD, 64-bit LBA (>2TB support), S.M.A.R.T support; - Direct connect up to 16 drives, Connect up to 122 drives with expander support, Up to 64TB LUN support; - Hot Spare support: Automatic rebuild, Global dedicated; - Enclosure management: SES (inband), SGPIO (sideband), Two 16-pin headers to illuminate fault LED Operating Temperature: Maximum ambient: 50癈 (40癈 w/iBBU) Operating Voltage: +3.3V
