Technical Specifications
- DSCP to 802.1p mapping- QoS on L2 layer using TCI field of VLAN header- Strict Priority Queuing- Weighted Round Robin Queuing- Voice VLAN / Auto QoS- L2/L3/L4 based ACL (Max 512 ACL)- Full/Half Duplex flow control, Back pressure for half duplex- Port rate limiting, shaping, all traffic by bps- Broadcast - packet rate control- Multicast - packet rate control- RADIUS / TACACS+ authentication and accounting- Port based authentication- MAC limitation per port- MAC based port security (static/dynamic)- HTTP, HTTPS- SNMP v1/v2c/v3, Trap (RFC 1215)- TCP/IP-based internets (RFC1213)- RMON v1/2 (RFC2819/RFC4502)- Received traffic- Transmit traffic- Received and transmit traffic- N to 1 Mirror- SNTP Network time- Configuration backup / restore- Firmware backup / upgrade- IP Clustering up to 36 switches- 48 Gbps switching fabric capacity- 35.7 Mpps- 16M flash memory- 128M DRAM- 8K MAC address capacity- 10K MTU/ Jumbo frames support- Auto-negotiation, auto-MDI/MDIX- 146,000 MTBF - Reset button- 10/100/1000 Base-TX Service ports- 24 10/100/1000Base-T Ports per Unit- 4 shared SFP built-in gigabit uplink ports- POE Support on all ports based on 802.3af- POE+ support based on 802.3at port 1-6- POE Power Indication and safety- Auto disable on the excess of total power- Dynamic Power Allocation- 185 Watt POE Power Budge - 19? Rack MountLGDES2024
