Out of Stock
Condition: New
Planar Part Number
997-8170-00
Product Name
MX55HDU-L-ERO-F
Technology
Commercial-grade direct view LCD
Diagonal
55 inches
Aspect Ratio
16:9
Native Resolution Panels
1920 x 1080
Tiled Bezel Width
3.7 mm
Brightness (typ)
800 cd/m or nits
Response Time (typ)
8 ms
Contrast ratio (full field)
3500:1
Full viewing angle
178 degrees
Backlight life (1/2 brightness)
50,000 Hrs
Mounted depth
3.8" wall to front of screen
Acoustic noise
Fanless operation
Operating temperature range
5 - 40 Degrees C
Operating humidity range
20-90% RH non-condensing
Backlight control
Individual and wall control
Backlight sensing and reporting
At display level
Display module position sensing
Auto-sensing integrated
Power Consumption (typ)
230 watts
Power supply voltage
100-230V AC 10%, 50-60 Hz
Power Status
Diagnostics LEDs, health monitoring and alerts
Safety regulations
Complies with EN60950, FCC Class A, CISPR22/85, CE, EU RoHS
Data Inputs
4 Single Link DVI Inputs, 1 Dual Link DVI Input
Control
IR Remote, RS232, Ethernet (optional)
Touch Options
Clarity Matrix MultiTouch Kits: MT6-6 Simultaneous Touch Points MT32-32 Simultaneous Touch Points
Touch Frame Dimensions
2.6" x 2.6" x 4.5"
Power for Touch System
100-240V AC, 50-60 Hz
OS Compatibility
Windows 8, Windows XP, Mac OS X, Android (limited to iStick), Linux
Fiber Video Extension Module Option
1 RU rack mount module drives up to 4 panels.
Fiber Video Extension Module Outputs
SFP multi-mode transceivers supports distances up to 300m from wall. Single mode compatible up to 10k from the wall.
Item Dimension (L inchxW inchxH inch)
48 x 27 x 4
Weight
170 lb
Warranty Information
3-Years
Planar 997-8170-01 LCD 997-8170-00 MX55HDU-L-ERO-F 55 Clarity Matrix Multi Touch Interactive Video Wall 1920x108
