Planar 997-7786-00 LCD 997-7786-00 LX55HDU-L-ERO 55inch 8ms 3500:1 1920x1080 HDMI/DisplayPort Retail

Clarity Matrix LX
LCD Video Walls for Lighter Use Applications

Clarity Matrix LX LCD video walls feature Full HD resolution and LED backlighting for outstanding tiled visual performance. Available in 46" and 55" sizes, Clarity Matrix LX models feature standard brightness of 450 nits for controlled ambient lighting and are ideal for lighter usage environments.

Video Walls Designed for Lower Power Consumption and Low Ambient Light Applications

Clarity Matrix LX is engineered to consume 17% less power than the standard Clarity Matrix MX model when operating at full brightness. Clarity Matrix LX was designed specifically for corporate and control room environments with relatively low ambient light conditions, while incorporating all the benefits of Clarity Matrix’s unique video wall design.

Planar's optional ERO (Extended Ruggedness and Optics) technology is available on Clarity Matrix LX video walls, providing an optically-bonded glass front that provides increased ruggedness and optical performance for public spaces or interactive touch applications.

Configure Your Custom Clarity Matrix Video Wall

The Clarity Matrix Calculator provides a simulated representation of your video wall along with important product specifications specific to your Clarity Matrix video wall design, including dimensions, weight, rack components, power consumption and heat load.

Product Name
LX55HDU-L-ERO

Technology
Commercial-grade direct view LCD

Screen Size
55inch

Aspect Ratio
16:9

Native Resolution Panels
1920x1080

Tiled Bezel Width
3.7mm

Brightness (Typical)
500 nits

Response Time (Typical)
8ms

Contrast Ratio (Typical)
3500:1

Full Viewing Angle (Typical)
178 Degrees

Backlight Life (1/2 Brightness)
50,000 Hours

Mounted Depth
3.7inch Wall to Front of Screen

Acoustic Noise
Fanless Operation

Heat Load
520 BTU Per Hour at 500 Nits

Operating Temperature
5 to 40 Degrees C

Operating Temperature Range
20 to 90% RH (Non-Condensing)

Backlight Control
Individual and Wall Control

Backlight Sensing and Reporting
At Display Level

Display Module Position Sensing
Auto Sensing Integrated

Power Consumption (Max)
165 Watts (Typical)

Power Supply Voltage
100 to 230V AC +/-10%, 50/60Hz

Power Status
Diagnostics LED
Health Monitoring and Alerts

Safety Regulations
Complies with EN60950, FCC Class A, CISPR22/85, CE, EU RoHS

Data Inputs
4 x HDMI Inputs
1 x DisplayPort Input

Control
IR Remote
RS232
Ethernet (Optional)

Touch Options
Clarity Matrix Multi Touch Kits: MT6-6 Simultaneous Touch Points MT32-32

Power for Touch System
100 to 240V AC, 50/60Hz

OS Compatibility
Windows 8, Windows XP, Mac OS X, Android (limited to iStick), Linux

Item Dimension (L"xW"xH")
47.81 x 26.98 x 3.7

Weight
170.00 lb

Warranty Information
3 Years
