Technical Specifications
Product Name
MX46HDU-L-ERO-100 Technology
LX55HDU-L Technology
Commercial Grade Direct View LCD Screen Size
55inch Aspect Ratio
16:9 Native Resolution Panels
1920x1080 Tiled Bezel Width
3.7mm Brightness (Typical)
500 nits Response Time (Typical)
8ms Contrast Ratio (Typical)
3500:1 Full Viewing Angle (Typical)
178 Degrees Backlight Life (1/2 Brightness)
50,000 Hours Mounted Depth
3.6inch Wall to Front of Screen Acoustic Noise
Fanless Operation Heat Load
520 BTU Per Hour at 800 Nits Operating Temperature
5 to 40 Degrees C Operating Temperature Range
20 to 90% RH (Non-Condensing) Backlight Control
Individual and Wall Control Backlight Sensing and Reporting
At Display Level Display Module Position Sensing
Auto Sensing Integrated
