Technical Specifications
Chipset:
Intel AX200
Complies with PCI Express 2.1 specification
Bus connector:
x1 PCI Express
Connector Type:
2 x 5dBi un-fixed and USB 4-Pin header (Bluetooth 5 operation)
Industry Standards:
IEEE802.11.ax, IEEE802.11.ac, IEEE802.11.n, IEEE802.11.b, IEEE802.11.g, IEEE802.11.a
Bluetooth:
Bluetooth 5.0
Security Methods:
WPA and WPA2 Personal and Enterprise, WPA3
Authentication Protocols:
802.1X EAP-TLS, EAP-TTLS/MSCHAPv2, PEAPv0-MSCHAPv2(EAP-SIM, EAP-AKA, EAP-AKA)
Encryption:
64-bit and 128-bit WEP, TKIP, 128-bit AES-CCMP, 256-bit AES-GCMP
Data Rates:
5G up to 2.4G (802.11ax 160MHz) / 2.4G up to 574M
Product:
Color:
Black
Connectors:
2 x 5dBi un-fixed and USB 4-Pin header
Environmental conditions:
Operating temperature:
32 to 140 degrees F
Storage temperature:
-14 to 158 degrees F
Relative humidity:
5% to 90% RH (non-condensing)
Certifications/Standards:
FCC, CE, RoHS Item Dimension (L"x W"x H")
3 x 5 x 1
Weight
1.00 LB
Warranty Information
1 Year
