J5800SSNX - Promise Technology Promise JBOD Expansion Subsystem 4U 24Bay 12G SAS Storage

Special Order
Ships in 1-2 weeks
Condition: New

$3,986.96  $5,382.40
Need 10+? Request a volume quote
 Free Shipping for this Item

Product Overview

The Promise JBOD Expansion Subsystem is designed to provide a robust and scalable storage solution with its 4U 24-bay configuration. Ideal for data centers and enterprise environments, it supports high-speed connectivity through 12G SAS interfaces, ensuring efficient data management and storage expansion capabilities. The subsystem is engineered for optimal performance with advanced management features, making it suitable for various high-demand applications.

Technical Specifications

  • Form Factor: 4U Design with 24 Drive Bays
  • External I/O Ports: Four SAS ports per controller with Mini SAS HD connectors; Wake-on-SAS feature supported.
  • Expander Management: Self-configuring expander for SAS domain management; T-10 zoning support; Smart cable detection for reliability.
  • Management Interfaces: LED status indicators; In-band SES enclosure management for alerts on operational specifications; Out-of-band RS232 serial CLI.
  • Enclosure Protocol: Compliant with ANSI T10 SES 2, SMP and includes extensive service report capabilities.
  • Voltage: Auto-ranging 100-240 Vac with a maximum current of 9A at 100 Vac and 4A at 240 Vac.
  • Temperature Range: Operational: 5°C to 40°C; Non-Operational: -40°C to 60°C.
  • Humidity: Operational 10%-90% (non-condensing); Non-Operational 5%-95% (non-condensing).
  • Acoustic Noise Levels: 55 dB typical; 65 dB maximum.
  • Shock Ratings: Operational 5G; Non-Operational 10G.
  • Vibration Resistance: Operational 0.3G; Non-Operational 1G.
  • Certifications: EMC Class A and various safety certifications (CE, FCC, UL/cUL, TUV).
  • Power Supply: Efficient 80PLUS GOLD certified redundant PSU.
  • Support: Available 24/7 web and phone support for customers, including product software and firmware access.
  • Package Contents: Includes the enclosure, power cords, quick start guide, product CD, rack mount kit, and SAS cables.
  • Dimensions: 30 x 23 x 12 inches; Weight: 61.00 lbs.
  • Warranty: 3 Years.

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Promise Technology
  • J5800SSNX
  • 704118107049
  • New
  • 1 lbs
  • 5 X 5 X 5
  • Jun 13, 2026
  • Sep 18, 2016
Product Identifiers: Brand: Promise Technology • Part #: J5800SSNX • UPC: 704118107049 • Category: Disk Controllers/RAID Cards
