J5320SDSS2 - Promise Technology Promise 2U 24-Bay Dual IOM SAS Storage Solution

Special Order
Ships in 1-2 weeks
Condition: New

$32,869.50  $44,373.83
Need 10+? Request a volume quote

Product Overview

The Promise 2U 24-Bay Dual IOM SAS storage solution is designed for high performance and scalability in data storage. With the capability to house up to 24 2.5 inch drives, this solution supports a diverse mix of SAS and SATA drives, ensuring flexibility and efficiency in data management. Its robust management features and compliance with industry standards provide reliability and ease of use for any data-intensive application.

Technical Specifications

  • Form Factor: 2U/24 Bay
  • Drive Support: Up to 24 2.5 inch drives
  • 3/6/12 Gb/s SAS, 3/6 Gb/s SATA HDD and SSD
  • Supports simultaneous mix of SAS and SATA drives
  • External I/O Ports (per controller): Four SAS ports with Mini SAS HD connectors (SFF-8644), with one port supporting Wake-on-SAS
  • Expander Management Features: Self-configuring expander, T-10 zoning support, End Device Frame Buffering, Smart cable support, SMP for SAS management
  • Management Interfaces: LED status indicators, in-band SES enclosure management, full subsystem management CLI via RS232 serial port
  • Enclosure Protocol and Management: ANSI T10 SES 2, SMP (SES over in-band SAS), Persistence Error Logging
  • Voltage: 100-240 Vac Auto-Ranging
  • Current (Maximum): 9A at 100 Vac / 4A at 240 Vac
  • Power Conversion Efficiency: >80% at 110V (>20% load), >80% at 240V (>20% load)
  • Temperature Range: Operational: 5°C to 40°C, Non-Operational: -40°C to 60°C
  • Humidity: Operational: 10% to 90% (Non-Condensing), Non-Operational: 5% to 95% (Non-Condensing)
  • Acoustic Noise Levels: 55 dB (Typical), 65 dB (Maximum)
  • Shock: Operational: 5G, 11ms duration, Non-Operational: 10G, 11ms duration
  • Vibration: Operational: 0.3G, 5 to 500 Hz, Non-Operational: 1G, 5 to 500 Hz
  • Safety and EMI Certification: EMC Class A: CE, FCC, VCCI, BSMI, RCM, KC; Safety: IEEE CB, UL/cUL, TUV
  • Item Dimension: 30 x 23 x 12 inches
  • Weight: 70 lb
  • Warranty Information: 3 Years

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Promise Technology
  • J5320SDSS2
  • 704118121748
  • New
  • 70 lbs
  • 30 X 12 X 23
  • Jun 06, 2026
  • Jun 22, 2017
Product Identifiers: Brand: Promise Technology • Part #: J5320SDSS2 • UPC: 704118121748 • Category: NAS Disk Arrays
