Technical Specifications
M/B Form Factor
ATX (12" x 9.6"), ATX (12" x 10"), EEB (12" x 13") Drive Bay
External: Hot-Swap 3.5" x 8 or 2.5" x 8 Internal: 2.5 HDD x 4 ( 2pcs for optional) Slim ODD x1 3.5 HDD x 1 (optional) Power Supply
Supports Form Factor: Single or 2U 1+1 Redundant Watt: Single 500W, Redundant up to 875W Indicator
Power Status, HDD, LANs, System Fail Activity LEDs Front Control Panel
Power Switch, ID Switch, System Reset, NMI, USB 3.0 x 2 Backplane
SATA (6Gb/s Supported) or Mini-SAS (6Gb/s Supported) or Mini SAS HD(12G/s Supported) Cooling Fan
Supports 80mm (Up to T 38 mm) PWM hot-Swap Fan x 4 Expansion Slot
Low Profile PCI Slot x 7 Material
Material: SGCC Thickness: 1.0 mm Rail Kit
Supports 28 Ball-bearing slide rail Item Dimension (L inchxW inchxH inch)
33 x 24 x 8 Weight
39.00lb Warranty Information
2 year on server cases, 3 year on PSU
