Product Overview
Provides power and data connection for up to four PoE network devices- Save installation cost by delivering data and power over existing network cables- Four 10/100/1000 Mbps IEEE 802.3at/af-compliant RJ45 PoE ports; one gigabit combo RJ45/SFP port- IEEE 802.3at/af-compliant RJ45 PoE/PoE+ output ports- Green Ethernet power-saving technology deactivates unused ports and adjusts power levels based on the cable length- Power output up to 30 watts per port- PoE power budget of 80 watts- Supports IEEE 802.3at and IEEE 802.3af-compliant PoE devices (wireless access points, VoIP phones, IP cameras)- Supports IEEE 802.3at/af detection and short circuit, overload and high-voltage protection- All RJ45 ports equipped with Auto-MDIX and auto-negotiation support- Complies with the IEEE 802.3az (Energy Efficient Ethernet EEE) specification- Store and forward switching architecture- 10 Gbps switch fabric- Supports jumbo frames up to 9 kBytes- IEEE 802.3x flow control for full duplex- Fanless design ideal for silent operation- Desktop-size metal case
