The RS232 to RS422/485 Converter provides exceptional data transmission capabilities with robust isolation protection, making it ideal for industrial and commercial applications. Designed with advanced chipset technology, this converter supports high-speed data rates and a variety of connection options for versatile use.
It ensures reliable performance with features like ESD and surge protection, accommodating long-distance transmission while maintaining data integrity. Perfect for reliable communication in challenging environments.
| Chipsets | Zywyn ZT485LEEN, SOIC8; Zywyn ZT3243LFEA, SSOP28 |
|---|---|
| Supports data transmission rates | up to 115200bps |
| Interfaces/Ports | 1x 9-Pin DB9 Female, 1x 5-Pin Terminal block, 1x 2-Pin Terminal block, DC power jack |
| Power Requirements | Input voltage: 9VDC - 24VDC (Terminal block-2 Wire) / 9VDC - 12VDC (DC power jack); Power consumption: 0.6W |
| Protection Features | 15KV ESD protection to RS-232 interface, 3KV isolation protection, 500W surge protection |
| Topology | Half/Full Duplex (auto detect) |
| Transmission distance | RS-232 side: 16ft (5m); RS-422/RS-485 side: up to 4000ft (1.2km) at 19,200bps |
| Color | Black |
| Power adapter | Input: 100-240VAC, 50-60Hz, 0.6A (Max); Output: 12VDC, 2A; Power plug dimensions: 5.4mm (OD) x 1.9mm (ID) x 9.5mm (L) |
| Certifications/Standards | FCC, CE, RoHS |
| Weight | 0.71lbs |
| Item Dimension | 5.79 x 7.36 x 1.97 inches |
| Warranty Information | 5 Years |
