Technical Specifications
CPU and Media Decoder
500 Mhz MIPS DRAM
DDR3 256MB at 1Ghz Weight
1.00 lbNAND
128MB Output Resolutions (selectable)
1280x720 (720p), 1920x1080 24Hz (1080p24), 1920x1080 30Hz (1080p30) Output I/O
HDMI v1.4 (backwards compatible to 1.2), MHL compatible Input I/O
Micro USB (when using USB instead of MHL to power HDCast Pro) WiFi
802.11 b/g/n 2T2R (single band), 300Mbps, 2.4Ghz Wireless Security
WPA, WPA2 Operating System Support
Android 4.x, Android 5.x, iOS 7.x, iOS 8.x, iOS 9.x, Mac OS 10.10.x, Windows 7, Windows 8.1, Windows 10 (Windows 10 for Phone coming soon) Android and Windows Mirroring
Mirror the entire screen of Android 4.x, Android 5.x, Windows 7, Windows 8.1 and Windows 10 devices using HDCast Pro Application iOS Mac OS X Mirroring
Mirror the entire screen of iOS 7.0.2, iOS 8.x, iOS 9.x, and Mac OS 10.10.x devices using HDCast Pro Application. Digital Media Sharing (Music/Video Player and Photo Viewer)
PlayTo, Push, or Cast Music, Pictures, and Videos from: Android, iOS, Mac OS X, and Windows to HDCast Pro using the HDCast Pro Application or Any DLNA/UPNP and Airplay compatible application or device to HDCast Pro Office Document Reader
MS Office 97-2003 (doc, xls, ppt) Office 2007-2016 (docx, xlsx, pptx)
Word Size Limitation: 100MB, Excel Size Limitation: 15MB, PowerPoint Size Limitation 19MB
Live Draw: Allows the presenter to make onscreen annotations by simply drawing on the screen Additional Document Reader support
Adobe Arcobat PDF Reader 1.0-4.0, iWorks 09 (Pages 09, Numbers 09, and Keynote 9) Android and iOS Cloud Storage support
Access Music, Pictures, Videos and Documents from Amazon Cloud, Box, Google Drive, OneDrive (Android 4.4.x or higher and iOS 7.0.x or higher) Cloud Video
Access YouTube, Vimeo, Hulu, and other video streaming services.1 Web Browser Sharing with Annotations
Share Webpages using the included Web Browser. Web Browser supports annotations for drawing and writing web pages. Works with YouTube, Instagram, and Twitter. For Hulu and YouTube Web Browser mode use Mirror mode in HDCast Application.1 AirView View
documents and photos that are currently displayed by HDCast Pro Broadcast using Front and Rear Camera
Display live camera video stream directly from Android, iOS.3 Subtitle Support
Standard SRT, SMI, SSA/ASS (UTF-8 / UTF-16 Font) at 8bits up to 1280x800 (mixed subtitles are not supported) Image Formats
BMP (No profile limit, no color space limit, and no size limit)
JPEG Baseline Profile (YUV400, YUV420, YUV422, YUV440, YUV444 at 8000x6000)
JPEG Progressive Profile (YUV400, YUV420, YUV422, YUV440, YUV444 at 10240x6400)
