29+Years
29+Years
Special Order
Ships in 1-2 weeks
Condition: New
Hubbell Adapter, Marine Adapter, Molded "Y", 2) 30A 125V Locking Plugs to 50A 125/250V, Locking Female, Yellow
Model: HBL64CM57| Application | "Y" Adapter |
| Color | Yellow |
| Insulation | Insulated Body |
| Item Type | Adapters |
| Material | Composite |
| Number Of Pins | Male- 50A 125V Twist-Lock® |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Operating Temperature | Max Continuous- 75 Degrees C, Minimum- -40 Without Impact |
| Performance | Environmental - Moisture Resistance - IP55 Suitability (Connectors) |
| Receptacle Type | Female- 30A 125V Twist-Lock® |
The Hubbell HBL64CM57 Y Adapter is designed for marine applications, enabling the connection of two 30A 125V power cords to a single 50A 125/250V dockside power inlet. This molded composite adapter provides a practical solution for scenarios where a vessel requires more power than a single 30A shore power connection can provide, or when only 30A outlets are available at the dock for a 50A-equipped boat. It features an insulated body and is rated for continuous operation up to 75 degrees C, with a minimum operating temperature of -40 degrees C without impact. The adapter's IP55 suitability ensures moisture resistance, making it suitable for demanding marine environments. This component facilitates efficient power management for IT infrastructure within marine settings, such as powering onboard network equipment or server racks, by consolidating available power sources.
This Y adapter is specifically designed for marine applications, allowing the consolidation of two 30A 125V power sources into a single 50A 125/250V connection for a boat or other marine vessel.
The adapter features two 30A 125V locking plugs for input cords and a 50A 125/250V locking female receptacle for connection to the dock's power inlet.
The Hubbell HBL64CM57 adapter has an IP55 suitability rating for moisture resistance, indicating it is protected against dust ingress and low-pressure water jets from any direction, making it suitable for outdoor and marine environments.
The adapter is rated for a maximum continuous operating temperature of 75 degrees C and a minimum operating temperature of -40 degrees C without impact.
HBL64CM57 - Hubbell Y Adapter 2 30A Cords - 50A 125V Dock
