H261-Z61 - Gigabyte 2U4N/DP/AMD EPYC/64 DDR4

Motherboard
MZ61-HD0 CPU
AMD EPYC 7001 series processor family
Dual processors, 14nm
Up to 32-core, 64 threads per processor
TDP up to 200W
NOTE: If only 1 CPU is installed, some PCIe or memory functions might be unavailable Socket
Per Node:
2 x LGA 4094
Total:
8 x LGA 4094
Socket SP3 Chipset
System on Chip Memory
Per node:
16 x DIMM slots
Total:
64 x DIMM slots
DDR4 memory supported only
8-Channel memory architecture
RDIMM modules up to 64GB supported
LRDIMM modules up to 128GB supported
Memory speed: 2666/2400/2133 MHz LAN
Per node:
2 x 1GbE LAN ports (1 x Intel I350-AM2)
1 x Dedicated management port
Total:
8 x 1GbE LAN ports (1 x Intel I350-AM2)
4 x Dedicated management ports
1 x 10/100/1000 CMC global management port
CMC: Chassis Management Controller, to monitor all status of computing nodes Video
Integrated in Aspeed AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200 at 60Hz 32bpp, DDR4 SDRAM
Management chip in CMC board:
Integrated in Aspeed AST1250 Audio
- Storage
Per node:
2 x 2.5" U.2, 4 x SATA/SAS hot-swappable HDD/SSD bays
Total:
8 x 2.5" U.2, 16 x SATA/SAS hot-swappable HDD/SSD bays
SAS card is required for SAS devices support RAID
Depends on RAID card (in option) Peripheral Drives
- Expansion Slots
Per node:
2 x Half-length low-profile slots with PCIe x16 (Gen3 x16 bus) from CPU_0
1 x OCP mezzanine slot with PCIe Gen3 x16 bus from CPU_0
2 x M.2 slots from CPU_0 and CPU_1:
- M-key
- PCIe Gen3 x4
- Supports NGFF-2242/2260/2280/22110 cards
Total:
8 x Half-length low-profile slots with PCIe x16 (Gen3 x16 bus) from CPU_0
4 x OCP mezzanine slots with PCIe Gen3 x16 bus from CPU_0
8 x M.2 slots from CPU_0 and CPU_1:
- M-key
- PCIe Gen3 x4
- Supports NGFF-2242/2260/2280/22110 cards Internal I/O
Per node:
2 x M.2 slots
1 x COM header
1 x TPM header
1 x BMC SGPIO header
1 x JTAG BMC header
1 x PLD header
1 x Clear CMOS jumper
1 x IPMB connector Front I/O
Per node:
1 x Power button with LED
1 x ID button with LED
1 x Status LED
Total:
4 x Power button with LED
4 x ID button with LED
4 x Status LED
1 x CMC status LED
Only one CMC status LED per system Rear I/O
Per node:
2 x USB 3.0
1 x VGA
2 x RJ45
1 x RJ45 MLAN
1 x ID LED
Total:
8 x USB 3.0
4 x VGA
8 x RJ45
4 x RJ45 MLAN
4 x ID LEDs
1 x CMC global management port
Only one CMC global management port per system Backplane I/O
24 x ports
12Gb/s and 6Gb/s compatible TPM
1 x TPM header with LPC interface
Optional TPM2.0 kit: CTM000 Power Supply
2 x 2200W redundant PSUs
80 PLUS Platinum
AC Input:
- 100-127V/ 14A, 47-63Hz
- 200-240V/ 12.6A, 47-63Hz
DC Output:
- Max 1200W/ 100-127V
+12.12V/ 95.6A
+12Vsb/ 3.5A
- Max 2200W/ 200-240V
+12.12V/ 178.1A
+12Vsb/ 3.5A
NOTE:
The system power supply requires C19 type power cord
2000W 80 PLUS Titanium PSU as an option System Management
Aspeed AST2500 management controller
GIGABYTE Management Console (AMI MegaRAC SP-X) web interface
Dashboard
JAVA Based Serial Over LAN
HTML5 KVM
Sensor Monitor (Voltage, RPM, Temperature, CPU Status etc.)
Sensor Reading History Data
FRU Information
SEL Log in Linear Storage / Circular Storage Policy
Hardware Inventory
Fan Profile
System Firewall
Power Consumption
Power Control
LDAP / AD / RADIUS Support
Backup and Restore Configuration
Remote BIOS/BMC/CPLD Update
Event Log Filter
User Management
Media Redirection Settings
PAM Order Settings
SSL Settings
SMTP Settings OS Compatibility
Windows Server 2012 R2 with Update
Windows Server 2016
Red Hat Enterprise Linux 7.4 (x64) or later
Red Hat Enterprise Linux 8.0 (x64) or later
SUSE Linux Enterprise Server 11.4 (x64) or later
SUSE Linux Enterprise Server 12.3 (x64) or later
SUSE Linux Enterprise Server 15 (x64) or later
Ubuntu 16.04 LTS (x64) or later
Ubuntu 18.04 LTS (x64) or later
VMware ESXi 6.5 Update1 or later
VMware ESXi 6.7 or later
Citrix Xenserver 7.1.0 CU2 or later
Citrix Xenserver 7.4.0 or later
Citrix Hypervisor 8.0.0 or later
