Technical Specifications
Model
P550B Type
Intel Form Factor ATX 12V v2.31 PFC
Active PFC(>0.9 typical) Input Voltage
100-240 Vac(full range) Input Current
8-4 A Input Frequency
60-50 Hz Output Capacity
550W Fan Type
120mm Hydraulic Bearing (HYB) Fan 80 PLUS
Bronze Efficiency
85% at typical load MTBF
>100,000 hours Protection
OVP/OPP/SCP/UVP/OCP/OTP Power Good Signal
100-500ms Hold Up Time
>16ms Cable Type
Flat, All black Connectors
ATX/MB 20+4 Pin x 1 : 550mmx1
CPU/EPS 4+4 Pin x 1 : 600mmx1
PCI-e 6+2 Pin x 2 : 550mm+150mmx1
SATA x 6 : 500mm+120mm+120mmx2
4 Pin Peripheral x 3 + 4-Pin floppy x 1 : 500mm+120mm+120mm+120mmx1 Item Dimension (L inchxW inchxH inch)
10 x 10 x 5
Weight
4.00 LB
Warranty Information
3 YEARS
