Technical Specifications
<b>CPU</b><br>Built in with an Intel Celeron Quad-Core J1900 SoC (2.0 GHz)<br>2 MB Cache<br> <b>Memory</b><br>2 x DDR3/DDR3L SO-DIMM sockets supporting up to 8 GB of system memory<br>Dual channel memory architecture<br>Support for DDR3/DDR3L 1333 MHz memory modules<br>Support for non-ECC memory modules<br> <b>Onboard Graphics</b><br>1 x D-Sub port, supporting a maximum resolution of 2560x1600 at 60Hz<br>1 x HDMI port, supporting a maximum resolution of 1920x1200 at 60Hz<br> <b>Audio</b><br>Realtek ALC887 codec<br>High Definition Audio<br>2/4/5.1/7.1-channel<br>Support for S/PDIF Out<br> <b>LAN</b><br>Realtek GbE LAN chip (10/100/1000 Mbit)<br> <b>Expansion Slots</b><br>1 x PCI slot<br> <b>Storage Interface</b><br>2 x SATA 3Gb/s connectors<br> <b>USB</b><br>Integrated in the SoC: <br>1 x USB 3.0/2.0 port on the back panel<br> 2 x GL850S chips: <br>8 x USB 2.0/1.1 ports (4 ports on the back panel, 4 ports available through the internal USB headers)<br> <b>Internal I/O Connectors</b><br>1 x 24-pin ATX main power connector<br>1 x 4-pin ATX 12V power connector<br>1 x CPU fan header<br>1 x system fan header<br>1 x front panel header<br>1 x front panel audio header<br>2 x SATA 3Gb/s connectors<br>2 x USB 2.0/1.1 headers<br>1 x serial port header<br>1 x S/PDIF Out header<br>1 x chassis intrusion header<br>1 x Clear CMOS jumper<br> <b>Back Panel Connectors</b><br>1 x PS/2 keyboard port<br>1 x PS/2 mouse porttor<br>1 x D-Sub port<br>1 x HDMI port<br>1 x front panel audio header<br>1 x parallel port<br>1 x USB 3.0/2.0 port<br>4 x USB 2.0/1.1 ports<br>1 x RJ-45 port<br>3 x audio jacks (Line In, Line Out, Mic In)<br> <b>I/O Controller</b><br>iTE I/O Controller Chip<br> <b>H/W Monitoring</b><br>System voltage detection<br>CPU/System temperature detection<br>CPU/System fan speed detection<br>CPU/System fan speed control<br> <b>BIOS</b><br>2 x 64 Mbit flash<br>Use of licensed AMI UEFI BIOS<br>Support for DualBIOS<br>PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0<br> <b>Bundle Software</b><br>Norton Internet Security (OEM version)<br>Intel Smart Connect Technology<br> <b>Operating System</b><br>Support for Windows 8.1/8<br> <b>Form Factor</b><br>Mini-ITX Form Factor 17.0cm x 17.0cm<br> <b>Item Dimension (L"xW"xH")</b><br>20 x 9 x 12<br> <b>Weight</b><br>14.17 lb<br> <b>Warranty Information</b><br>3 years<br>
