Gigabyte GA-7PESH3 Motherboard for Intel Xeon E5-2600

Special Order
Ships in 1-2 weeks
Condition: New

$796.57  $1,075.37
 Free Shipping for this Item

Product Overview

The Gigabyte GA-7PESH3 is a robust motherboard designed to cater to the needs of server and workstation applications. It supports Intel's Xeon E5-2600 processor family and is equipped with advanced memory and storage options, making it ideal for high-performance computing tasks. The motherboard features a strong LAN configuration, integrated graphics, and extensive connectivity options, ensuring seamless integration into any server environment.

Technical Specifications

  • Dimension: EEB 330W x 305H (mm)
  • CPU: Dual LGA2011 Socket, Supports Intel Xeon processor E5-2600 family
  • Chipset: Intel C602
  • Memory: 8 x DIMM slots supporting Registered or ECC Unbuffered memory, Quad channel architecture
  • Maximum Memory: Up to 256GB RDIMM ECC, Up to 64GB UDIMM ECC, 1066/1333/1600 MHz
  • LAN: Dual Gigabit Ethernet LAN ports (Intel 82574L), Management LAN
  • Video: Integrated Aspeed AST2300, 2D VGA Adapter, 1920x1200@60Hz
  • Audio: 7.1+2 HD audio channels
  • SAS: 8 x SAS 6Gb/s ports with LSI SAS 2008 controller
  • SATA: 2 x SATA III 6Gb/s ports and 4 x SATA II 3Gb/s ports
  • RAID Functions: Intel SATA RAID 0/1/10/5, LSI SAS RAID 0/1/10/1E
  • Expansion Slots: 1 x PCIe 3.0 x16, 3 x PCIe 3.0 x16 (Gen3 x8), 3 x PCIe 3.0 x8, or 4 x PCIe 3.0 x16 via PCIe switch (supports 4-way NVIDIA SLI and AMD CrossFireX)
  • Internal I/O Connectors: 1 x 24 pin power, 2 x 8 pin power connectors, USB 3.0 and USB 2.0 headers, front audio header, and various SATA/SAS connectors
  • Back Panel Connectors: 4 x USB 3.0 ports, 4 x USB 2.0 ports, PS/2, audio jacks, RJ45, VGA, and COM port
  • Server Management: Aspeed AST2300, IPMI 2.0, iKVM
  • Power Supply Connectors: 1 x 24 pin, 2 x 8 pin connectors
  • Supported Operating Systems: VMware vSphere, VMware ESXi, Windows Server 2008, Red Hat ELES, SuSE ES
  • Item Dimensions: 14.25 x 13 x 3 inches
  • Weight: 5.3 lbs
  • Warranty: 3 Years

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • GIGABYTE
  • GA-7PESH3
  • 818313017307
  • New
  • 5.3 lbs
  • 0 X 0 X 0
  • Feb 19, 2026
  • Apr 11, 2014
Product Identifiers: Brand: Gigabyte • Part #: GA-7PESH3 • UPC: 818313017307
