SKU: AZTEKS1R9C |  Mfg. Part: FWF-90D-BDL-950-36  | UPC: 094922406484  |
 1 Reviews  |     Share Make an offer

FWF-90D-BDL-950-36 - Fortinet FORTIGATE 90D W 3YR 24X7 FC FG SERVICE BDL FORTINET

Special Order
Ships in 1-2 weeks
Condition: New

$3,042.70  $4,107.65

AUTHORIZED
Need 10+? Request a volume quote
 Free Shipping for this Item

Product Overview

FWF-90D-BDL-950-36 - Fortinet FORTIGATE 90D W 3YR 24X7 FC FG SERVICE BDL FORTINET

Technical Specifications

Main Specifications

Product Description Fortinet FortiGate 90D - security appliance - with 3 years FortiCare 24X7 Comprehensive Support + 3 years FortiGuard
Device Type Security appliance
Bundled Services 3 years FortiCare 24X7 Comprehensive Support + 3 years FortiGuard
Form Factor External
Hard Drive 32 GB x 1
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Performance Firewall throughput (1518-byte packet size): 3.5 Gbps ? Firewall throughput (512-byte packet size): 3.5 Gbps ? Firewall throughput (64-byte packet size): 3.5 Gbps ? VPN throughput (512-bit IPSec): 1 Gbps ? Firewall throughput: 5.3 Mpps ? VPN throughput (IPSec): 1 Gbps ? VPN throughput (SSL): 35 Mbps ? IPS throughput: 275 Mbps ? Antivirus throughput: 65 Mbps ? Antivirus throughput (proxy): 35 Mbps
Capacity Client to gateway IPSec VPN tunnels: 1000 ? Gateway to gateway IPSec VPN Tunnels: 200 ? Concurrent sessions: 1500000 ? New sessions per second: 4000 ? Firewall policies: 5000 ? Concurrent SSL VPN users: 200 ? Virtual domains: 10 ? Number of FortiAP devices: 16 ? Number of FortiToken devices: 100 ? Number of FortiClient devices: 200
Power AC 120/230 V (50/60 Hz)
Dimensions (WxDxH) 9.2 in x 8.8 in x 1.7 in
Weight 3.53 lbs
Manufacturer Warranty 3 years warranty

Extended Specifications

General
Device Type Security appliance
Bundled Services 3 years FortiCare 24X7 Comprehensive Support + 3 years FortiGuard
Width 9.2 in
Depth 8.8 in
Height 1.7 in
Weight 3.53 lbs
Processor / Memory / Storage
Hard Drive 32 GB x 1
Networking
Form Factor External
Connectivity Technology Wired
Data Link Protocol Ethernet, Fast Ethernet, Gigabit Ethernet
Performance Firewall throughput (1518-byte packet size): 3.5 Gbps ? Firewall throughput (512-byte packet size): 3.5 Gbps ? Firewall throughput (64-byte packet size): 3.5 Gbps ? VPN throughput (512-bit IPSec): 1 Gbps ? Firewall throughput: 5.3 Mpps ? VPN throughput (IPSec): 1 Gbps ? VPN throughput (SSL): 35 Mbps ? IPS throughput: 275 Mbps ? Antivirus throughput: 65 Mbps ? Antivirus throughput (proxy): 35 Mbps
Capacity Client to gateway IPSec VPN tunnels: 1000 ? Gateway to gateway IPSec VPN Tunnels: 200 ? Concurrent sessions: 1500000 ? New sessions per second: 4000 ? Firewall policies: 5000 ? Concurrent SSL VPN users: 200 ? Virtual domains: 10 ? Number of FortiAP devices: 16 ? Number of FortiToken devices: 100 ? Number of FortiClient devices: 200
Features 3G/4G USB Dongle Support
Expansion / Connectivity
Interfaces 14 x 1000Base-T - RJ-45 ? 2 x 1000Base-T - RJ-45 (WAN) ? 2 x USB - Type A
Miscellaneous
Compliant Standards UL, VCCI, C-Tick, ICSA IPSec certified, ICSA Firewall certified, cUL, ICSA Antivirus, CB, FCC Part 15 B, ICSA Network IPS
Power
Power Device External power adapter
Voltage Required AC 120/230 V (50/60 Hz)
Power Consumption Operational 21.8 Watt
Manufacturer Warranty
Service & Support Limited warranty - advance parts replacement - 3 years - response time: next business day ? Technical support - phone consulting - 3 years ? Product info support - e-mail consulting - 3 years ? Product info support - web knowledge base access - 3 years ? Technical support - web support - 3 years ? New releases update - 3 years ? Virus definitions update - 3 years ? Intrusion definitions update - 3 years ? URL database update - 3 years ? E-mail database update - 3 years
Environmental Parameters
Min Operating Temperature 32 ?F
Max Operating Temperature 104 ?F
Humidity Range Operating 20 - 90% (non-condensing)

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Fortinet
  • FWF-90D-BDL-950-36
  • 094922406484
  • New
  • 2 lbs
  • 0 X 0 X 0
  • Feb 19, 2026
  • Dec 30, 2025
Product Identifiers: Brand: Fortinet • Part #: FWF-90D-BDL-950-36 • UPC: 094922406484 • Category: Firewall & VPN
