Technical Specifications
Temperature Range
Operating: 0 C to +25 C
Storage Shipping: -40 C to +70 C Humidity
85% on Operating, 95% on Storage Dielectric Withstand
Primary Frame Ground 1800V AC for 1 Second Efficiency
82% Minimum Rise Time
Less than 20ms Hold-Up Time
16ms Minimum at Nominal Input Voltage Power Good Signal
Power on Delay Time 100 to 500ms, off Delay 1ms Minimum (TTL and CMOS Compatible) Leakage Current
Less Than 3.5mA at 264V AC, 50Hz MTBF
100,000 Hours on Maximum Lad at +25 C Input Characteristics
Input Range: 90 to 264V AC (RMS), Full Range Input
Frequency: 47 to 63 Hz
Input Current: Max 8.0A at 115V AC, 4A at 230V AC
Inrush Current: No Damage Output Characteristics (Minimum Load/Normal Load/Maximum Load/Load Reg/Line Reg/Ripple/Noise)
+3.3V: 0.5A, 14.77A, 24A, +/-5%, +/-1%, 50mV P-P
+5V: 0.3A, 12.31A, 20A, +/-5%, +/-1%, 50mV P-P
+12V1: 0.5A, 15.62A, 18A, +/-5%, +/-1%, 120mV P-P
+12V2: 0.5A, 15.62A, 18A, +/-5%, +/-1%, 1200mV P-P
-12V: 0A, 0.28A, 0.3A, +/-10%, +/-2%, 200mV P-P
+5Vsb: 0A, 2.3A, 2.5A, +/-5%, +/-1%, 50mV P-P Item Dimension (L"xW"xH")
6 x 6 x 4
Weight
4.40 lb
Warranty Information
1 Year
