Is the FSP20061DL-B204 in stock?

The FSP20061DL-B204 is currently out of stock. Please check back or request a quote for availability.

SKU: TJIB2YNPDA | Mfg. Part: FSP20061DL-B204 | UPC: 677808611068 |

1 Reviews | Share

Sparkle Power FSP20061DL-B204 200W DC to DC Flex ATX Power Supply with Ball Bearing Fan

Name: FSP20061DL-B204 Sparkle Power 200W DC to DC Flex ATX Power Supply with Ball Bearing Fan
Brand: Sparkle Power
SKU: TJIB2YNPDA
Price: 177.68 USD
Availability: OutOfStock
Rating: 5 (1 reviews)

Out of Stock
Condition: New

$177.68 ~~$239.87~~

Free Shipping for this Item

Product Overview

The 200W DC to DC Flex ATX Power Supply is designed for reliable performance with an innovative ball-bearing fan for efficient cooling. Operating within a broad temperature range, it provides stable voltage outputs for various computing applications while ensuring efficiency and durability.

With a total output of 200W and a compact design, this power supply is suitable for high-demand systems, making it an ideal choice for both system builders and enthusiasts.

Technical Specifications

Temperature Range: Operating: 0°C - +50°C; Storage/Shipping: -20°C - +80°C
Humidity: 5-95% during operation and storage
Dielectric Withstand: 1800V AC for 2 seconds to primary frame ground
Efficiency: 80% minimum
Rise Time: Less than 20ms
Power Good Signal: Power-on delay 100-500ms; off delay 1ms minimum
MTBF: 100,000 hours under maximum load at +25°C
Input Range: 36-72V DC; Normal: 48V DC
Input Current: Max 8A at 48V DC
Inrush Current: No damage
Output Voltage (Min Load/Normal Load/Max Load/Ripple Noise): +3.3V: 0.0A/6A/12A 5% 50mV P-P; +5V: 1.0A/6A/12A 5% 50mV P-P; +12V: 1.0A/8A/16A 5% 120mV P-P; -12V: 0.0A/0.25A/0.5A 10% 120mV P-P; +5Vsb: 0.0A/1.0A/2.0A 5% 50mV P-P
Power: +3.3V and +5V total output not to exceed 80W; Total output for this power supply is 200W
Dimensions: 6" x 3.2" x 1.6" (L x W x H)
Weight: 2.00 lb
Warranty: 1 Year
