Technical Specifications
OVERVIEW Precision Mounting Holes
Two M2x0.4 on each of two sides and bottom One 1/4-20 threaded hole on top Spectral Band
7.5 - 13.5 micrometer Thermal Imager
Uncooled VOx Microbolometer Zoom
Yes - Adjustable in App and via PWM CONNECTIONS and COMMUNICATIONS Analog Video Output
Yes ENVIRONMENTAL and APPROVALS Non-Operating Temperature Range
-55oC to +95oC Operating Temperature Range
-20oC to +50oC Operational Altitude
+40,000 feet IMAGING and OPTICAL Color palettes
Yes - Adjustable in App and via PWM Full Frame Rate
30 Hz (NTSC), 25 Hz (PAL) Image Optimization for sUAS
Yes Invertable Image
Yes - Adjustable in App Lens Options
9 mm, 35o x 27o Scene Presets and Image Processing
Yes - Adjustable in App Sensor Resolution
336 x 256 Lens Options (FOV for NTSC Analog Output)
9 mm, 34o x 26o
