FD-P-IA2G-850 - Fractal Design Ion Gold 850W 80 PLUS Gold Certified â?? Fully Modular ATX Power Supply

Specifications

• Mfr Part Number: FD-P-IA2G-850
• Features:
  • 80PLUS Gold Efficiency rating
  • ATX 2.52 compatible, including tighter timing limits
  • DC-DC design for more precise output and modern compatibility
  • Fully compatible with modern components
  • Fully modular design for reduced clutter and maximum ease of installation
  • Capacitors include Premium Japanese 105°C for reliability and durability
  • Large custom-tailored 140 mm fan with exceptionally low minimum speed
  • 150 mm depth allows for compact installation or extra cable room
  • 7-year warranty and a full electrical protection suite for peace of mind
• Input:
  • Voltage: 100 ~ 240 VAC
  • Current: 10-5 A
  • Frequency Range: 50 ~ 60 Hz
• MTBF: 100,000 hours
• PSU specification compliance:ATX12V 2.52 / EPS12V 2.92
• Maximum power: 850W
• Fan: 140 mm LLS bearing Fractal Design Dynamic series fan
• PFC: Active
• PSU color:Black
• Cable color: Black
• Modular cables:Fully modular
• 80 PLUS® Certification:80 PLUS GOLD Certified
• Output: +3.3V @ 20A, +5V @ 20A, +12V @70.8A, +5VSB @ 3A, -12V @ 0.3A
• Connectors: 1x 24pin ATX Main Connector, 2x 8pin (4+4) EPS Power Connector, 6x 8pin(6+2)PCI-Express Connector, 8x SATA Connectors, 3x Peripheral,
• Approvals: CE, FCC, KCC, TUV, cTUVus, EAC, RCM, CCC, BSMI, CB, RoHS, WEEE
• Standby efficiency:ErP 2013 (<0.45W @230 VAC, 45 mA load on +5Vsb)
• +12V Rails:Single
• Sleep State Compliance:C6/C7
• Safeguards:
  • â??Over voltage protection
  • Under voltage protection
  • Over power protection
  • Short circuit protection
  • Over current protection
  • Over temperature protection
• Unit Dimensions (LxWxH): 150 x 150 x 86 mm
• Unit Weight: 2.41 kg
• Package Dimensions (LxWxH): 325 x 110 x 210 mm
• Package Weight: 2.81 kg
