Promise Technology E5600FDNX Promise E5600FDNX 3U 16-Bay Dual Controller FC RAID System

Out of Stock
Condition: New

$7,486.27  $10,106.46

Product Overview

The Promise E5600FDNX is a robust 3U 16-Bay Dual Controller 16G FC RAID subsystem tailored for high-performance data storage solutions. Designed without drives, it supports advanced RAID configurations and features to ensure optimal data integrity and accessibility.

This system is perfect for enterprises needing reliable storage with advanced management capabilities. Packed with features like hot spares, advanced cache mirroring, and intelligent error handling, the E5600FDNX guarantees top-tier performance and reliability.

Technical Specifications

  • Form Factor: 3U/16 Bay
  • Hot spares: Global or dedicated with revertible option
  • Max LUNs per subsystem: 1024
  • Max LUNs per array: 32
  • Advanced Storage Features:
    • - Advanced Cache Mirroring over PCIe Gen3
    • - Simple, drag-and-drop LUN Masking and Mapping
    • - Asymmetric LUN Unit Access (ALUA)
    • - Volume Copy
    • - PerfectFlash - Non-Disruptive Software Update
    • - I/O performance power monitoring tools
    • - USB Service Log
    • - LDAP Support for central user management
  • Background Activities:
    • - Media Patrol
    • - Background Synchronization
    • - Foreground Initialization
    • - Rebuild
    • - Redundancy Check
    • - Disk SMART Polling
    • - Online Capacity Expansion (OCE)
    • - RAID Level Migration (RLM)
    • - UPS Monitoring
    • - Feature-rich task scheduler for background activities
  • PerfectRAID Features:
    • - Predictive Data Migration (PDM)
    • - Intelligent Bad Sector Remapping
    • - SMART Error Handling
    • - NVRAM Error Logging
    • - Disk Slot Power Control
    • - Read/Write Check Table
    • - Write Hole Table
  • GreenRAID Features:
    • - Four levels of advanced power management disk drive (MAID) support
    • - Efficient 80Plus Certified power supplies
  • Management Interfaces:
    • - Web Based management using WebPAM PROe (Ethernet)
    • - Command Line Interface (CLI) or Command Line Utility (Serial Port or Ethernet via Telnet, SSH)
    • - Third Party Management Support via SNMP, CIM
  • Supported Operating Systems:
    • Windows Server 2008, 2012, HyperV, OS X 10.x, RHEL 6.5, 6.6, SLES 11, VMWare ESX v6.x
  • Voltage: 100--240 Vac Auto--Ranging
  • Current (Maximum): 9A at 100 Vac, 4A at 240 Vac
  • Power Conversion Efficiency: >80% at 110V (>20% load), >80% at 240V (>20% load)
  • Temperature Range:
    • Operational: 5°C to 40°C
    • Non-Operational: -40°C to 60°C
  • Humidity:
    • Operational: 10% to 90% (Non-Condensing)
    • Non-Operational: 5% to 95% (Non-Condensing)
  • Acoustic Noise Levels:
    • 55 dB (Typical)
    • 65 dB (Maximum)
  • Shock:
    • Operational: 5G, 11 ms duration
    • Non-Operational: 10G, 11ms duration
  • Vibration:
    • Operational: 0.3G, 5 to 500 Hz
    • Non-Operational: 1G, 5 to 500 Hz
  • Safety and Emission Certification:
    • - EMC Class A: CE, FCC, VCCI, BSMI, RCM and KC
    • - Safety: IEEE CB, UL/cUL and TUV

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Promise Technology
  • E5600FDNX
  • 704118109203
  • New
  • 1.51 lbs
  • 31 X 13 X 24
  • Mar 07, 2026
  • Sep 18, 2016
Product Identifiers: Brand: Promise Technology • Part #: E5600FDNX • UPC: 704118109203
