Promise Technology E5300FSQS6 Promise 2U 12-Bay 16G FC RAID with 12x6TB SAS HDD

Out of Stock
Condition: New

$11,473.02  $15,488.58
 Free Shipping for this Item

Product Overview

The Promise 2U 12-Bay 16G FC RAID subsystem is designed to provide high performance and reliability for enterprise storage needs. Equipped with 12x6TB 7200 RPM 12G SAS hard drives, it offers a raw capacity of 72TB, catering to demanding data environments.

This system features advanced storage capabilities including cache mirroring, LUN masking, and extensive management interfaces, making it ideal for both virtualized environments and traditional IT setups.

Technical Specifications

  • Form Factor: 2U/12 Bay
  • Hot spares: Global or dedicated with revertible option
  • Max LUNs per subsystem: 1024
  • Max LUNs per array: 32
  • Advanced Storage Features:
    • Advanced Cache Mirroring over PCIe Gen3
    • Drag-and-drop LUN Masking and Mapping
    • Asymmetric LUN Unit Access (ALUA)
    • Volume Copy
    • Non-Disruptive Software Update (PerfectFlash)
    • I/O performance power monitoring tools
    • USB Service Log
    • LDAP Support for central user management
  • Background Activities:
    • Media Patrol
    • Background Synchronization
    • Foreground Initialization
    • Rebuild
    • Redundancy Check
    • Disk SMART Polling
    • Online Capacity Expansion (OCE)
    • RAID Level Migration (RLM)
    • UPS Monitoring
  • PerfectRAID Features:
    • Predictive Data Migration (PDM)
    • Intelligent Bad Sector Remapping
    • SMART Error Handling
    • NVRAM Error Logging
    • Disk Slot Power Control
    • Read/Write Check Table
    • Write Hole Table
  • GreenRAID Features:
    • MAID support with four levels of advanced power management
    • 80Plus Certified power supplies
  • Management Interfaces:
    • Web-Based management with WebPAM PROe
    • Command Line Interface (CLI)
    • Third Party Management Support via SNMP, CIM
  • Supported Operating Systems: Windows Server 2008, 2012, HyperV, OS X 10.x, RHEL 6.5, 6.6, SLES 11, VMware ESX v6.x
  • Power Specifications:
    • Voltage: 100-240 Vac Auto-Ranging
    • Current: 9A at 100 Vac, 4A at 240 Vac
    • Power Conversion Efficiency: >80% at 110V (>20% load), >80% at 240V (>20% load)
  • Environmental:
    • Operational Temperature: 5°C to 40°C
    • Non-Operational Temperature: -40°C to 60°C
    • Operational Humidity: 10% to 90% (Non-Condensing)
    • Non-Operational Humidity: 5% to 95% (Non-Condensing)
    • Acoustic Noise Levels: 55 dB (Typical), 65 dB (Maximum)
    • Shock: Operational 5G, Non-Operational 10G
    • Vibration: Operational 0.3G, Non-Operational 1G
  • Safety and Emission Certification: EMC Class A: CE, FCC, VCCI, BSMI, RCM, KC; Safety: IEEE CB, UL/cUL, and TUV

Product Details

  • Manufacturer:
  • Model Number:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Promise Technology
  • E5300FSQS6
  • 704118112241
  • New
  • 54.67 lbs
  • 18 X 3 X 20
  • Mar 21, 2026
  • Sep 18, 2016
Product Identifiers: Brand: Promise Technology • Part #: E5300FSQS6 • UPC: 704118112241
