General InformationSynology DiskStation DS718+ features a quad-core processor with AES-NI hardware encryption engine, providing outstanding performance and data encryption acceleration along with real-time transcoding of 4K content. DS718+ is ideal for protecting critical assets, and sharing files across different platforms. Synology DS718+ is backed with Synology's 3-year limited warranty.Compact Storage with Outstanding PerformanceFeaturing an Intel Celeron J3455 quad-core 1.5 GHz processor with burst frequency of 2.3 GHz and 2 GB RAM, Synology DiskStation DS718+ is designed for small or growing businesses pursuing a compact and powerful shared storage solution, offering the flexibility to expand up to 6 GB RAM to process intensive workloads. With Link Aggregation enabled, DS718+ delivers up to 226 MB/s reading and 188 MB/s writing under RAID 1 configuration. With AES-NI, DS718+ provides encrypted data transmission at over 226 MB/s reading and 184 MB/s writing.DS718+ comes with three USB 3.0 ports and dual Gigabit LAN ports supporting failover and Link Aggregation modes. The 2-bay DS718+ can support up to 7 drives with Synology DX5172 expansion unit.Btrfs: Next Generation StorageDS718+ integrates the Btrfs file system, bringing the most advanced storage technologies to meet the management needs of modern businesses: Flexible Shared Folder/User Quota System provides comprehensive quota control on all user accounts and shared folders. Advanced snapshot technology with customizable backup schedule allows up to 1,024 copies of shared folder backups and 65,000 copies of system-wide snapshots, without occupying huge storage capacity and system resources. File or folder level data restoration brings huge convenience and saves time for users who wish to restore only a specific single file or folder. File self-healing: Btrfs file system can auto-detect corrupted files with mirrored metadata, and recover broken data using the supported RAID volumes, which include RAID 1, 5, 6, and 10. Comprehensive Business ApplicationsPowered by the innovative Synology DiskStation Manager (DSM), DS718+ comes fully-equipped with applications and features designed specifically for small or growing businesses: Windows AD and LDAP support allow easy integration with existing business directory services without recreating user accounts. Windows ACL support provides fine-grained access control and efficient privilege settings, allowing DS718+ to fit seamlessly into current infrastructure. Internet file access is simplified by the encrypted FTP server and Synology File Station, a web-based file explorer. HTTPS, firewall, and IP auto-block support ensure file sharing over the Internet is protected with a high level of security. Application Privileges controls access to applications and packages based on each individual account, user group, or IP address. MailPlus allows your business to set up a secure, reliable, and private mail server while giving your employees a modern mail client for receiving and sending messages. The powerful Collaboration Suite integrates Synology Office, Calendar and Chat, ensuring secure and high-performance private communications and allowing your organizations to easily manage and control the relevant content. StorageNumber of Hard Drives Supported: 2Number of Solid State Drive Supported: 2
Technical Specifications
CPU Model Intel Celeron J3455 CPU Architecture 64-bit CPU Frequency Quad Core 1.5 burst up to 2.3 GHz Hardware Encryption Engine (AES-NI) Y Hardware Transcoding Engine H.264 (AVC), H.265 (HEVC), MPEG-2 and VC-1, maximum resolution: 4K (4096 x 2160), maximum frame rate per second (FPS): 30 System Memory 2 GB DDR3L Memory Module Pre-installed 2GB (1 x 2GB) Total Memory Slots 2 Memory Expandable up to 6 GB (2 GB + 4 GB) Drive Bays 2 Maximum Drive Bays with Expansion Unit 7 RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support) USB 3.0 Port 3 eSATA Port 1 USBCopy Y Internal Drives Btrfs EXT4 External Drives Btrfs EXT4 EXT3 FAT NTFS HFS+ exFAT Notes exFAT Access is purchased separately in Package Center. System Fan 92 mm x 92 mm x 1 pcs Fan Speed Mode Full-Speed Mode Cool Mode Quiet Mode Brightness adjustable front LED indicators Y Power Recovery Y Noise Level 18.4 dB(A) Scheduled Power On/Off Y Wake on LAN/WAN Y Power Supply Unit / Adapter 65W AC Input Power Voltage 100V to 240V AC Power Frequency 50/60 Hz, Single Phase Power Consumption 20.1 W (Access) 9.1 W (HDD Hibernation) British Thermal Unit 68.58 BTU/hr (Access) 31.05 BTU/hr (HDD Hibernation) Operating Temperature 5oC to 40oC (40oF to 104oF) Storage Temperature -20oC to 60oC (-5oF to 140oF) Relative Humidity 5% to 95% RH Certification FCC Class B CE Class B BSMI Class B Notes Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s). Maximum Internal Volume Number 512 Maximum iSCSI Target Number 32 Maximum iSCSI LUN 256 iSCSI LUN Clone/Snapshot, Windows ODX Y Supported RAID Type Synology Hybrid RAID Basic JBOD RAID 0 RAID 1 RAID 5 (with Expansion Unit) RAID 6 (with Expansion Unit) RAID 10 (with Expansion Unit) RAID Migration Basic to RAID 1 Basic to RAID 5 (with Expansion Unit) RAID 1 to RAID 5 (with Expansion Unit) RAID 5 to RAID 6 (with Expansion Unit) Volume Expansion with Larger HDDs Synology Hybrid RAID RAID 1 RAID 5 (with Expansion Unit) RAID 6 (with Expansion Unit) Volume Expansion by Adding a HDD Synology Hybrid RAID RAID 5 (with Expansion Unit) RAID 6 (with Expansion Unit) JBOD (with Expansion Unit) Global Hot Spare Supported RAID Type Synology Hybrid RAID RAID 1 (with Expansion Unit) RAID 5 (with Expansion Unit) RAID 6 (with Expansion Unit) RAID 10 (with Expansion Unit) SSD Read/Write Cache Y SSD TRIM Y Maximum Local User Accounts 2048 Maximum Local Groups 256 Maximum Shared Folder 512 Maximum Shared Folder Sync Tasks 8 Maximum Concurrent CIFS/AFP/FTP Connections 500 Windows Access Control List (ACL) Integration Y NFS Kerberos Authentication Y High Availability Manager Y Log Center Y Syslog Events per Second 800 VMware vSphere 6 with VAAI Y Windows Server 2012 Y Windows Server 2012 R2 Y Citrix Ready Y OpenStack Y Antivirus by McAfee (Trial) Y Central Management System Y Chat Y Maximum Users 1500 Notes The number of concurrent HTTP connections for Chat was configured to the maximum. CPU and RAM usage were both under 80% when the number of maximum users was reached. For tested models with expandable memory, the maximum amount of RAM was installed. Cloud Station Server Y Maximum Number of Concurrently Connected Devices 500 Maximum Number of Concurrently Connected Devices (with RAM expansion) 1500 Maximum Number of Synced Files (btrfs) 1,000,000 / single file reaction time 862 ms Maximum Number of Synced Files (ext4) 1,000,000 / single file reaction time 351 ms Notes The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time. For more information on file processing capability, please refer to the reaction time for file processing. File reaction time refers to the preparation time required for other devices to start downloading a 1KByte file from a Synology NAS after the file has been added to the NAS. RAM expansion was not used during testing. Non-encrypted shared folders were used during the aforementioned testing. Document Viewer Y Download Station Y Maximum Concurrent Download Tasks 80 exFAT Access (optional) Y MailPlus / MailPlus Server Y Free Email Accounts 5 Recommended MailPlus Client Number Up to 90 (Btrfs) / 90 (ext4) Maximum Server Performance 831,000 (Btrfs) / 966,000 (ext4) emails per day, approx. 25.4 GB (Btrfs) / 29.5 GB (ext4) Notes The CPU and RAM usages were both under 80% when testing recommended client numbers. For tested models with expandable memory, the maximum amount of RAM was installed. Read-write SSD cache was enabled in 5-bay (and above) NAS models with 2 SSDs units installed. The performance of the mail system will slightly decrease in high-availability mode due to data synchronization between the two servers. Functions that were enabled in all of the tests above: anti-spam, anti-virus, DNSBL, greylist, content scan, full-text search (English only). Media Server Y DLNA Compliance Y Office Y Maximum Users 200 Maximum Simultaneous Editing Users 80 Notes CPU and RAM usage were both under 80% when the number of maximum users was reached. For tested models with expandable memory, the maximum amount of RAM was installed. Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM Snapshot Replication Y Maximum Snapshots per Shared Folder 1024 Maximum Snapshots of all Shared Folder 65536 Surveillance Station Y
