DISPL10MA - Startech ACTIVE 10M/32.8FT DISPLAYPORT V1.2 CABLE | Aztek Computers
29+Years
SKU: EFUA8035RH |  Mfg. Part: DISPL10MA  | UPC: 065030854221  |  0 Reviews  |     Share

DISPL10MA - Startech ACTIVE 10M/32.8FT DISPLAYPORT V1.2 CABLE SUPPORTS 4K (3840 X 2160 AT 30HZ)/10.8

2 Available
Condition: New

$44.20  $59.67
 Free Shipping for this Item

Product Overview

StarTech DISPL10MABrand NewIncludes 2 Year WarrantyProduct # DISPL10MAConnect DisplayPort®-equipped devices up to 10m away with no signal loss. The DISPL10MA 10m Active DisplayPort® Cable features a built-in active signal booster for a connection distance of up to 30 feet (10m) between your DisplayPort-enabled devices - almost double the DisplayPort connection distance limitation of 16ft, with no signal loss. This durable yet lightweight active DP cable features a thinner 32 AWG wire construction that allows for a more flexible installation with minimal clutter. Plus, the cable features built-in amplifier circuitry which actively boosts the DisplayPort signal with no external power needed. The 10m cable offers a bandwidth of 10.8 Gbps with support for maximum resolutions up to WQXGA (2560?1600) and optional audio support. The cable is both HDCP and DPCP capable, which ensures that digitally protected content is displayed properly. This 10-meter Active DisplayPort cable is backed by StarTech.com's 2-year Warranty. Please Note: This cable features unidirectional architecture which requires that the cable is installed in the correct direction. Please refer to the "source" and "display" labels on the DisplayPort connectors, in order to ensure that the display device (monitor, projector etc.) and the DisplayPort source are connected properly. DISPL10MA Features: Cable Type: DisplayPort Cable Length: 32.81 ft Connector on First End: 1 x 20-pin DisplayPort Male Digital Audio/Video Connector on Second End: 1 x 20-pin DisplayPort Male Digital Audio/Video Connector Plating: Nickel Plated Shielding: Yes Device Supported: Audio/Video Device Device Supported: Monitor Device Supported: Projector Green Compliant: Yes Green Compliance Certificate/Authority: RoHS

Expert Overview

The StarTech DISPL10MA is a 10-meter (32.81 ft) active DisplayPort cable designed for extending video and audio connections without signal degradation. This cable is suitable for IT environments requiring longer DisplayPort runs than standard passive cables, which typically have distance limitations. It features a built-in active signal booster that eliminates the need for external power, supporting a bandwidth of 10.8 Gbps. The cable supports resolutions up to 3840 x 2400 and is compatible with HDCP and DPCP for protected content. Its thinner 32 AWG construction allows for more flexible installations. This product addresses the challenge of maintaining signal integrity over extended distances for DisplayPort-enabled devices such as monitors, projectors, and workstations, making it appropriate for conference rooms, digital signage, or extended desktop setups.

Technical Specifications

General Information
Manufacturer:StarTech.com
Manufacturer Part Number:DISPL10MA
Manufacturer Website Address:http://www.startech.com
Brand Name:StarTech.com
Product Name:10m Active DisplayPort Cable - DP to DP M/M
Marketing Information:

The DISPL10MA 10m Active DisplayPort® Cable features a built-in active signal booster for a connection distance of up to 30 feet (10m) between your DisplayPort-enabled devices - almost double the DisplayPort connection distance limitation of 16ft, with no signal loss.

This durable yet lightweight active DP cable features a thinner 32 AWG wire construction that allows for a more flexible installation with minimal clutter. Plus, the cable features built-in amplifier circuitry which actively boosts the DisplayPort signal with no external power needed.

The 10m cable offers a bandwidth of 10.8 Gbps with support for maximum resolutions up to WQXGA (2560r1600) and optional audio support. The cable is both HDCP and DPCP capable, which ensures that digitally protected content is displayed properly.

This 10-meter Active DisplayPort cable is backed by StarTech.com's 2-year Warranty.

Please Note: This cable features unidirectional architecture which requires that the cable is installed in the correct direction. Please refer to the "source" and "display" labels on the DisplayPort connectors, in order to ensure that the display device (monitor, projector etc.) and the DisplayPort source are connected properly.


Packaged Quantity:1
Product Type:A/V Cable
Technical Information
Cable Type:DisplayPort
Cable Length:32.81 ft
Connector Type on First End:DisplayPort Digital Audio/Video - Male
Connector on First End Details:1 x 20-pin DisplayPort Digital Audio/Video - Male
Connector Type on Second End:DisplayPort Digital Audio/Video - Male
Connector on Second End Details:1 x 20-pin DisplayPort Digital Audio/Video - Male
Connector Plating:Nickel
Features:
  • Active
  • Signal Booster
  • Flexible
  • HDCP
  • DPCP
  • Latching Connector
  • Multi-Stream Transport (MST) Support
  • EMI Protection

Conductor:Copper
Shielding:Yes
Jacket Type:CMG
Device Supported:
  • Audio/Video Device
  • Monitor
  • Projector
  • Notebook
  • Workstation
  • Amplifier
  • Graphics Card

American Wire Gauge:32 AWG
Data Transfer Rate:10.8 Gbit/s
Supported Resolution:3840 x 2400
Physical Characteristics
Product Color:Black
Jacket Material:Polyvinyl Chloride (PVC)
Height:0.5"
Width:0.8"
Weight (Approximate):1 lb
Miscellaneous
Compatibility:FirePro S9000/7000, W8100/7100/5100 or R5000 Graphic Cards
Certifications & Standards:
  • FCC
  • CE

Environmentally Friendly:Yes
Environmental Certification:RoHS
Country of Origin:China
Warranty
Limited Warranty:2 Year

Product Details

  • Manufacturer:
  • Model Number:
  • ASIN:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • TAA Compliant:
  • Country of Origin:
  • STARTECH
  • DISPL10MA
  • B00I9PEHCK
  • 065030854221
  • New
  • 0.05 lbs
  • 10 X 1 X 9
  • Sep 25, 2026
  • Feb 14, 2014
  • Yes
  • CN
Product Identifiers: Brand: Startech • Part #: DISPL10MA • UPC: 065030854221 • ASIN: B00I9PEHCK • Category: USB Cables • TAA Compliant

Frequently Asked Questions

What is the maximum resolution supported by this cable?

The StarTech DISPL10MA cable supports maximum resolutions up to 3840 x 2400. It also supports WQXGA (2560x1600).

Does this cable require external power for its active signal booster?

No, the cable features built-in amplifier circuitry that actively boosts the DisplayPort signal without requiring any external power.

Is this cable compatible with protected content?

Yes, the cable is both HDCP and DPCP capable, which ensures that digitally protected content is displayed properly.

Are there any specific installation requirements for this cable?

Yes, this cable features unidirectional architecture. It must be installed in the correct direction, so refer to the "source" and "display" labels on the DisplayPort connectors for proper connection.
