Intel DBM10JNP2SB Server Board M10JNP2SB for Entry-Level Servers

Out of Stock
Condition: New

$273.47  $369.18
 Free Shipping for this Item

Product Overview

The Intel Server Board M10JNP2SB is designed for entry-level server applications in small to medium businesses (SMBs), web hosting, content delivery, and storage solutions. This single socket solution supports the Intel Xeon E processor family and offers a flexible uATX form factor, ideal for rack and pedestal chassis.

With a maximum memory capacity of 128 GB and support for DDR4 UDIMM ECC memory, it ensures reliable performance in critical computing environments. The board also includes various expansion options and I/O specifications, making it a versatile choice for various server setups.

Technical Specifications

  • Product Collection: Intel Server Board M10JNP Family
  • Status: Launched
  • Compatible Product Series: Intel Xeon E Processor
  • Form Factor: uATX
  • Socket: Socket H4, FCLGA 1151
  • TDP: 95 W
  • Included Items: I/O shield
  • Chipset: Intel C246 Chipset
  • Max Memory Size: 128 GB
  • Memory Types: DDR4 UDIMM ECC, 2666 MT/s, 1.2V
  • Max Number of Memory Channels: 2
  • Max Number of DIMMs: 4
  • ECC Memory Supported: Yes
  • Graphics Output: DDI ports
  • Expansion Slots: 1 x PCIe x4 Gen 3, 2 x PCIe x8 Gen 3
  • USB Configuration: 4 x External USB 3.1 Gen2 ports, 2 x USB 3.1 Gen1 ports
  • Total Number of SATA Ports: 8
  • RAID Configuration: RAID 0/1/10/5 (Intel RSTe)
  • Integrated LAN: 4 x 1Gbps LAN ports + 1 x 1Gbps management port
  • Max CPU Configuration: 1
  • TPM Version: 2.0 support
  • Item Dimensions: 13 x 11 x 3 inches
  • Weight: 4.00 LB
  • Warranty Information: 3-year limited

Product Details

  • Manufacturer:
  • Model Number:
  • ASIN:
  • UPC:
  • Condition:
  • Weight:
  • Dimensions:
  • Updated:
  • Added:
  • Intel
  • DBM10JNP2SB
  • B083W17T3T
  • 735858433853
  • New
  • 4 lbs
  • 5 X 5 X 5
  • Mar 07, 2026
  • Dec 04, 2019
Product Identifiers: Brand: Intel • Part #: DBM10JNP2SB • UPC: 735858433853 • ASIN: B083W17T3T • Category: Motherboards
