Technical Specifications
RoHS Compliance
Yes Form factor
2 U Standard Drive Bays
3.5" Drives: 2
5.25" Drives: 2 Indicators
Power, HDD, Temperature, Fan (Fan/Temp require sensor board TC-ISF08 ) Switches
Power, Reset Supported PSU Type
2U Expansion Slots
3 Security
Front Bezel Key Lock Material of Front Bezel
Aluminum alloy Material of Handle
SECC Zinc-Coated Steel Material of Main Chassis
1.2mm SECC Zinc-Coated Steel (Japan Made) Color of Front Bezel
Blue Color of Main Chassis
Black Front Connector
2x USB 2.0 Motherboard Size
12 x 9.6 (ATX, microATX, mini-ITX) Cooling Fan
1x80mm Optional Fan:
60mm x3 (bracket DD-FANGUARD-6 required) Notes
- low profile backplate option, P/N: DD-200-LP-PCI.
- cross bar option for redundant power supplies, P/N: DD-200-R2U-BAR. Item Dimension (L inchxW inchxH inch)
27 x 22 x 9
Weight
39.00 lb
Warranty Information
1 year
