Technical Specifications
Form Factor
4U chassis support for motherboards up to size
13.68" x 13", E-ATX and ATX
Processor Support
Supports dual, single Intel / AMD processors
Available Colors
Black Expansion Slots
7x PCI expansion slots
Drive Bays
Hot-swap
24x 3.5" Hot-swap SAS Drive Bays w/ SES2 (dual-channel)
SAS or enterprise SATA HDD only recommended
Optional
2x 2.5" Hot-swap SAS Drive Bays on rear side of Chassis Backplane
4U Expander Backplane, features:
SAS2 compliance
Scalability through cascading
6Gb support
Inband SES-2 Enclosure Management
SAS/SATA support
Single input/output SFF 8087 connectors Front Panel
Buttons
Power On/Off button
System Reset button
LEDs
Power LED
Hard drive activity LED
2x Network activity LEDs
System Overheat LED
Power Fail LED System Cooling
Fans
3x 6300 RPM Hot-swap PWM Cooling Fans
2x 5000 RPM Hot-swap Rear Exhaust PWM Fans
System Monitoring
Chassis intrusion switch Power Supply with Power Distributor
920W high-efficiency (94%+) AC-DC Redundant power supplies with PMBus and I2C
AC Input
100-240 V, 50-60 Hz, 11-4.5 Amp
DC Output
4 Amp at +5V standby
75 Amp at +12V
With Power Distributor
+5V: 45 Amp
+3.3V: 24 Amp
-12V: 0.6 Amp
Certification
80PLUS Platinum Certified Regulatory (Power Supply)
Power Supply Safety / EMC
USA - UL listed, FCC
Canada - CUL listed
Germany - TUV Certified
Europe/CE Mark
EN 60950/IEC 60950-Compliant Item Dimension (L"xW"xH"):
26 x 17 x 7
Weight:
75 lb
Warranty Information:
1 Year
