CSE-836BA-R920B - Supermicro SC836 BA-R920B

Form Factor
3U chassis support max. motherboard size- 13.68" x 13", E-ATX, ATX

Processor Support
Supports dual, single Intel / AMD processors

Available Color
Black

Expansion Slots
7x full-height full-length expansion slots Drive Bays
Hot-swap
16x 3.5" Hot-swap SAS Drive Bays with SES2 (dual-channel) and optional 2x 2.5" Hot-swap SAS Drive Bays on rear side of Chassis SAS or enterprise SATA HDD only recommended Backplane
3U Direct Attached Backplane, features:
3Gb/6Gb support
SES-2 Enclosure Management Support
SAS/SATA support
Four SFF 8087 connectors Peripheral Drives
DVD-ROM
Slim DVD-ROM Drive (Optional)
Floppy
Slim 1.44MB Floppy Drive (Optional) Front Panel
Buttons
Power On/Off button
System Reset button
LEDs
Power LED
Hard drive activity LED
2x Network activity LEDs
System Overheat LED
Power fail LED
Ports
2x USB Ports and DB9 COM Port

System Cooling
Fans
3x 80mm Hot-swap 4-pin PWM Fans
2x 80mm Rear-exhaust 4-pin PWM Fans

System Monitoring
Chassis intrusion switch Power Supply with Power Distributor
920W high-efficiency (94%+) AC-DC Redundant power supplies with PMBus and I2C
AC Input
100-240 V, 50-60 Hz, 11-4.5 Amp
DC Output
4 Amp at +5V standby
75 Amp at +12V
With Power Distributor
+5V: 45 Amp
+3.3V: 24 Amp
-12V: 0.6 Amp
Certification
80PLUS Platinum Certified Regulatory (Power Supply)
Power Supply Safety / EMC
USA - UL listed
Canada - CUL listed
Germany - TUV Certified
EN 60950/IEC 60950-Compliant
CB Report
CCC Certification Item Dimension (L"xW"xH"):
40 x 48 x 80

Weight:
80 lb

Warranty Information:
3 Years
