Technical Specifications
Form Factor
3U chassis support for max. motherboard size - 13.68inch x 13inch Processor Support
Supports dual, single Intel / AMD processors Dimensions
Height : 5.2inch (132mm)
Width : 17.2inch (437mm)
Depth : 25.5inch (648mm)
Gross Weight : 75 lbs (34.0kg)
Available Colors : Black Expansion Slots
7x full-height full-length expansion slots Drive Bays
Hot-swap : 8x 3.5inch SAS / SATA Hot-swap drive trays, SAS or enterprise SATA HDD only recommended SAS / SATA Backplane
1x 2U SAS / SATA Backplane with Enclosure Management Peripheral Drives
DVD-ROM : Slim DVD-ROM Drive Front Panel
Buttons
Power On/Off button
System Reset button
LEDs
Power LED
Hard drive activity LED
2x Network activity LEDs
System Overheat LED
Power fail LED System Cooling
Fans
3x 80mm Hot-swap PWM Fans
2x 80mm Rear-exhaust PWM Fans Operating Environment (System)
Operating Temperature Range : 10 - 35oC (50o - 95oF)
Non-Operating Temperature Range : -40 - 70oC (-40o - 158oF)
Humidity Range : 8 - 90% non-condensing
Non-Operating Humidity Range : 5 - 95% non-condensing Power Supply with Power Distributor
920W high-efficiency (94%+) AC-DC Redundant power supplies with PMBus and I2C
AC Input
- 100-240 V, 50-60 Hz, 11-4.5 Amp
DC Output
- 4 Amp at +5V standby
- 75 Amp at +12V
With Power Distributor
- +5V: 50 Amp
- +3.3V: 30 Amp
- -12V: 0.6 Amp
Certification : 80PLUS Platinum Certified Regulatory (Power Supply)
Power Supply Safety / EMC
USA - UL listed
Canada - CUL listed
Germany - TUV Certified
EN 60950/IEC 60950-Compliant
CB Report
CCC Certification Warranty
1 YEARS PARTS AND 3 YEARS LABOR
