CSE-815TQC-R706WB2 - Supermicro Case CSE-815TQC-R706WB2 1U 4x3.5 inch Hot-Swap SAS/SATA 700/750W Brown Box

Form Factor
Optimized for X11 WIO (W series) motherboards Processor Support
Single and Dual Intel and AMD processors Available Color
Black Expansion Slots
2 full-height full-length expansion slot(s)
1 low-profile expansion slot(s) Drive Bays
4 x 3.5" hot-swap SAS/SATA
SAS or enterprise SATA HDD only recommended Backplane
1U 4-Port 12Gbps Backplane Support 4x3.5" SAS3/SATA3 HDD/SSD Front Panel
Buttons:
- Power On/Off button
- System Reset Button
- Unit Identification (UID) button
LEDs:
- 2 Network Activity LEDs
- Fan Fail/System Over Heat LED
- HDD activity LED
- Power Status LED
- Unit Identification (UID) LED Systems Cooling
Fans: 4 x 40x56mm counter-rotation PWM fan(s) Operating Environment (System)
Operating Temperature Range: 5^oC - 35^oC (41^oF - 95^oF)
Non-Operating Temperature Range: -40^oC - 70^oC (-40^oF - 158^oF)
Operating Relative Humidity Range: 8% - 90% (non-condensing)
Non-Operating Relative Humidity Range: 5% - 95% (non-condensing) Power Supply
1U Redundant 700/750W Single Output Power Supply Platinum level, 54.5mm width
Power Efficiency: 94%
Total Output Power and Input:
- 700W with Input 100 - 140Vac
- 750W with Input 200 - 240Vac
AC Input Frequency: 50-60Hz
Output Type: Backplanes (gold finger)
+12V:
- Max: 58A / Min: 0.5A (100Vac - 140Vac)
- Max: 62A / Min: 0.5A (200Vac - 240Vac)
+5Vsb: Max: 3A / Min: 0A
Power Distributor:
- PDB-PT112-S2424
- O/P: 12V/54A
- +5V Max: 25
- +3.3V Max: 25
- -12V Max: 0.6
Certification: Platinum Certified Regulatory (Power Supply)
Power Supply Safety / EMC:
- BSMI
- CCC
- CE/EMC
- FCC class A
- UL/CB
- UL/CUL Item Dimension ( L inch x W inch x H inch)
NA Weight
36.00 lb Warranty Information
3 years labor, 1 year parts, 1 year limited cross ship
