Technical Specifications
<b> Form Factor</b><br> 1U chassis, support motherboard size ATX 12" x 10" and Micro ATX 9.6" x 9.6".<br> <b> Processor Support</b><br> Dual and Single Intel and AMD processors<br> <b> Available Color</b><br> Black<br> <b> Expansion Slots</b><br> 1 full height expansion slot(s) <br> <b> Drive Bays</b><br> 4 x 3.5" hot-swap SAS/SATA <b> Backplane</b><br> 1U 4-Port 12Gbps Backplane Support 4x3.5 <b> Peripheral Drives</b><br> Optional 1 x Slim DVD-ROM Drive<br> Optional 1 x USB + COM port tray<br> <b> Front Panel</b><br> <b> Buttons</b><br> Power On/Off button<br> System Reset Button<br> <b> LEDs</b><br> 2 Network Activity LEDs<br> HDD activity LED<br> Power Status LED<br> System Information LED<br> <b> Systems Cooling</b><br> <b> Fans</b><br> 4 x 40x28mm PWM fan(s) <b> Operating Environment (System) </b><br> <b> Operating Temperature Range</b><br> 5<sup>o</sup>C - 35<sup>o</sup>C (41<sup>o</sup>F - 95<sup>o</sup>F) <br> <b> Non-Operating Temperature Range</b><br> -40<sup>o</sup>C - 70<sup>o</sup>C (-40<sup>o</sup>F - 158<sup>o</sup>F) <br> <b> Operating Relative Humidity Range</b><br> 8% - 90% (non-condensing) <br> <b> Non-Operating Relative Humidity Range</b><br> 5% - 95% (non-condensing) <br> <b> Power Supply</b><br> 1U 400W Redundant Power Supply Platinum with PMBUS, W54.5xL220xH40mm<br> <b> Power Efficiency</b><br> 94%<br> <b> Total Output Power and Input</b><br> 400W with Input 100 - 240Vac<br> 400W with Input 200 - 240Vdc<br> <b> AC Input Frequency</b><br> 50-60Hz<br> <b> Dimensions (L x W x H) </b><br> 220 x 54.5 x 40.25 mm<br> <b> Output Type</b><br> Backplanes (gold finger) <br> <b> +12V</b><br> Max: 33A (100Vac - 240Vac) <br> <b> +5Vsb</b><br> Max: 3A / Min: 0A<br> <b> Certification</b><br> Platinum Certified<br> <b> Regulatory (Power Supply) </b><br> <b> Power Supply Safety / EMC</b><br> BSMI<br> CCC<br> CE/EMC<br> FCC class A<br> UL/CB<br> UL/CUL<br> <b> Weight </b><br> 33.50 LB <br> <b> Warranty Information</b><br> 1 Year <br>
