Technical Specifications
Form Factor
9.8"-Depth Mini 1U chassis support for maximum motherboard size - 6.75" x 6.75"
Processor Support
Single Processor Support
Available Colors
Black Expansion Slots
Up to 1x full-height, half-length PCI expansions slot
Drive Bays
Internal
Bay 1x 3.5" Internal Drive Bay with 1x Half-height, Half-length PCI OR 2x 3.5" Internal Drive Bay OR 2x 2.5" Internal Drive Bay with 1x Full-height, Half-length PCI OR 4x 2.5" Internal Drive Bay Ony SAS or enterprise SATA HDD recommended Front Panel
Buttons
Power On/Off button
System Reset button
LEDs
Power LED
Hard drive activity LED
2x Network activity LEDs
System Overheat LED I/O Ports
1x VGA, IPMI, 4xLANs, 1x COM, 4xUSB, 1xKeyboard/Mouse
Power Supply
200W Low Noise AC-DC power supply with PFC
AC Voltage
100 - 240V, 50-60Hz, 2.6 Amp Max
+5V
8.0 Amp (max.)
+5V standby
2.0 Amp (max.)
+12V
16 Amp (max.)
-12V
0.5 Amp (max.)
+3.3V
8.0 Amp (max.)
Certification
Gold Certified Regulatory (Power Supply)
Power Supply Safety / EMC
USA - UL listed, FCC
Canada - CUL listed
CCC Certification
EN 60950/IEC 60950-Compliant
Europe/CE Mark
Germany - TUV Certified Item Dimension (L"xW"xH"):
25.8 x 18.3 x 6.1
Weight:
17.35 lb
Warranty Information:
1 Year
