Technical Specifications
Form Factor
2U chassis support for motherboard size - 13.68" x 13", E-ATX and ATX Processor Support
Supports Dual Single Intel/AMD Processor Expansion Slot
7x Low-profile expansion slots Drive Bays
HDD: 8x 2.5" Hot-swap SAS/SATA HDD bays for SAS or enterprise SATA HDD only
Peripheral: 1 x 5.25inch Peripheral Drive Bay SAS Backplane
1 x 2U SAS Backplane with Enclosure Management Front Panel
Buttons:
-Power On/Off Button
System Reset Button
LEDs:
-Power LED
-Hard Drive Activity LED
2 x Network Activity LEDs
-System Overheat LED
Power Fail LED System Cooling
Fans: 3x 80x38mm high-performance, high-quality PWM fans System Monitoring
Chassis Intrusion Switch Operating Environment
Operating Temperature Range: 5 C -35 C (41 C 95 F)
Non-Operating Temperature Range: -40 C t- 70 C (-40 F 158 F)
Operating Relative Humidity: 8% - 90% (Non-Condensing)
Non-Operating Relative Humidity Range: 5% - 95% (Non-Condensing) Power Supply with Digital Switching Control and PMBus 1.2
600W AC Power Supply with PFC (24-Pin)
AC Voltage: 100-240 V, 50-60 Hz, 7.5 Amp Max
+5V: 18 Amp
+5V Standby: 3 Amp
+12V: 49 Amp
-12V: 0.5 Amp
+3.3V: 15 Amp
Certification: 80 PLUS PLATINUM Item Dimension (L"xW"xH")
38 x 26.5 x1 0.5
Weight
63.70 lb
Warranty Information
1 Year
